Coarse
Use this to set the oscillator frequency. The range can be adjusted
over 6 octaves.
Fine
Use this knob to detune the oscillators with respect to one another.
Detuning and then mixing two oscillators produces vibrations that
result in a more lively sound. The range can be adjusted over
approximately one octave.
Octave Up/Down
Unlike the original model, our remake is equipped with a switch that
allows you to set each oscillators' frequency in octave steps over a
range of 3 octaves.
Keyboard On/Off
You can use this switch to disconnect Oscillator 1 from the key-
board in order to use it as an LFO. The oscillator is now running at
a much slower rate. Instead of frequencies spanning several octa-
ves in the higher ranges, the "coarse" setting now ranges from just
0.2 Hz to 20 Hz.
Sync On/Off
This setting activates the hard sync from Oscillator 2 to Oscillator 1.
Hard sync makes the Oscillator 2 waveform re-start with each cycle
of the Oscillator 1 waveform. This process transfers the pitch from
Oscillator 1 to Oscillator 2. Depending on the "coarse" setting and
Oscillator 2's frequency modulation, you can create different over-
tone spectra each time you re-start the waveform.
