Velleman components TRC6 Bedienungsanleitung

1. Introduction & Features
Thank you for buying the TRC6! Please read the manual thoroughly before bringing this device into service.
If the device was damaged in transit, don't use it and contact your dealer.
• Up to 4 TRC6 tanks can be used simultaneously provided the 4 tanks each have a different ID.
• Not suitable for children under 3 years of age.
• Remove all packaging before giving the TCR6 to children, never leave children to play with it unattended and make sure
nobody touches a tank while it is in motion to avoid hair or fingers getting stuck in the tank.
• Do not try to control the same tank with 2 different remote controls.
• Do not operate the TRC6 in direct sunlight, in water or on sand.
2. Remote Control / Charging Station
1. on/off switch
2. Steering trim buttons: to adjust the wheel alignment of the tank.
3. Channel selection switch
4. Charging port with cover
5. Backward key
6. Forward key
7. Operation LED: lights up when the remote is switched on
8. Right turn key
9. Left turn key
10. Charging LED: lights up while the tank is being recharged
11. Charging port open button / tank release button
12. Fire buttons
3. Operation
The remote control operates on 4 AA alkaline batteries. Make sure to install them properly: open the battery compartment cover
at the bottom of the remote control, insert the four AA batteries securely respecting the polarity. Close the battery compartment
cover.
Open the charging port (#4) by pressing button #11 and put the tank in the charging port (the square
notches at the bottom facing forward). The red charging LED (#10) lights up to indicate the tank is being
charged. A full charge normally takes 2 to 3 minutes and allows for ±6 minutes of playing time. When
charging is complete, the charging LED is switched off. Press the tank release button to remove the tank
from the charging port (see figure at the right) and close it.
Switch on the remote control (#1) and the tank (at the bottom). Make sure the channel selection switch
(#3) is set to the channel of your tank. Drive the tank around and try to point the barrel of the tank towards another tank. Press
fire (#12). A shot will be effective from a distance of 25 to 30cm. When you fire, your tank exhibits kickback to simulate real tank
combat. When a tank is hit, the tank will spin 360 degrees. The tank LED will start flashing and will flash faster after each
additional hit until the fourth hit, when the tank will switch off. You can then reset the tank by setting the power switch at the
bottom to 'off' and then to 'on' again.
The information in this manual is subject to change without prior notice.
1. Inleiding en kenmerken
Dank u voor uw aankoop! Lees deze handleiding grondig voor u het toestel in gebruik neemt. Als het toestel werd beschadigd
tijdens het transport, gebruik het dan niet en raadpleeg uw dealer.
• Tot 4 TRC6 tanks kunnen tegelijk worden gebruikt op voorwaarde dat iedere tank op een ander kanaal werkt.
• Niet geschikt voor kinderen jonger dan 3 jaar.
• Verwijder alle verpakking voor u de TCR6 aan kinderen geeft, laat deze er nooit zonder toezicht mee spelen en zorg ervoor
dat niemand een tank aanraakt terwijl deze in beweging is.
• Probeer niet dezelfde tank te besturen met 2 verschillende afstandsbedieningen.
• Gebruik de TRC6 niet in direct zonlicht, in water of op zand.
TRC6
TRC6 – MINI BATTLE TANK
TRC6 – MINI GEVECHTSTANK
1 VELLEMAN
