Standard Mode; Led Indicator - Cudy GS1006P Benutzerhandbuch

DIP Switch 1

Standard mode

Numbers 1-4 correspond to PoE Port1 ~ Port4.
This mode makes the PoE Switch operate as a general switch and all PoE ports operate at 10/100/1000Mbps
auto-negotiation
Extend mode
This mode makes the PoE ports of PoE Switch operate at auto-negotiation 10Mbps speed duplex mode only,
but the delivery distance of PoE power and network data can reach 200m
DIP Switch 2
Default:
The factory default mode, can normal communication between port 1~6.
VLAN:
1-4 port can be isolated each other but 1-4 port can connect to 5/6 port after open VLAN to stop
broadcast storm to increase forwarding rate of frame.
Note: After changing the mode, no power failure is required to make the corresponding configuration take
effect

LED indicator

LED Color
Power Orange
DATA Green
PoE Orange
Off: No Power supply.
Light: Indicates the switch has power.
Off: No device is connected to the corresponding port.
Light: Indicates the link through that port is successfully
Established at 10/100/1000Mbps.
Blink: Indicates that the Switch is actively sending or
Receiving data over that port.
Off: No PoE powered device (PD) connected.
Light: There is a PD connected to port, which
Supply power successfully.
Function
