- Seite 1 Artisan Technology Group is your source for quality new and certified-used/pre-owned equipment SERVICE CENTER REPAIRS WE BUY USED EQUIPMENT • FAST SHIPPING AND DELIVERY Experienced engineers and technicians on staff Sell your excess, underutilized, and idle used equipment at our full-service, in-house repair center We also offer credit for buy-backs and trade-ins •...
- Seite 2 ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ BARRACUDA 2LP ○ ○ ○...
-
Seite 3: Inhaltsverzeichnis
Wichtige Sicherheitshinweise ....... 5 Technical support services ........10 General description ..........13 Initial setup information ........... 19 Kühlung des Systems .......... 24 © 1995 Seagate Technology, Inc. All rights reserved Publication Number: 83328920, Rev. E October1995 ® ® Seagate... -
Seite 4: Preface
It provides support services, performance specifications, and initial setup information. Additional information is available in the Barracuda 2LP Product Manual (part number 83328930). Contact your Seagate sales representative if you need to order this publica- tion. Electrostatic discharge protection Caution. -
Seite 5: Important Safety Information And Precautions
• Ground yourself to the drive whenever the drive elec- tronics are or will be exposed. Connect yourself to ground with a wrist strap (Seagate part number 12263496). Connection may be made to any grounded metal assembly. As a general rule, remember that you and the drive electronics must all be grounded to avoid potentially damaging static discharges. - Seite 6 Barracuda 2LP Installation Guide, Rev. E The procedures in this manual and labels on the unit contain warnings and cautions that must be carefully read and followed to minimize or eliminate the risk of personal injury. The warnings point out conditions or practices that may endanger you or others.
- Seite 7 UL1950, IEC950, EN60950, CSA C22.2 950, and VDE0805. Seagate takes all reasonable steps to ensure that its products are certifiable to currently accepted standards. Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
-
Seite 8: Wichtige Sicherheitshinweise
This unit is a component part and as such is not meant to comply with FCC or similar national requirements as a stand-alone unit. Engineering radiated emissions test results are available through the Seagate Safety Depart- ment to assist the subsystem designer. Wichtige Sicherheitshinweise Vorsicht. - Seite 9 Barracuda 2LP Installation Guide, Rev. E werden. Wir empfehlen die Verfahren in diesem Handbuch als effektive Methoden zur Wartung und Reparatur der Einheit. Einige Verfahren erfordern Spezialwerkzeuge; diese müssen zur sachgemäßen Ausführung der Wartungsarbeiten und aus Sicherheitsgründen den Empfehlungen entsprechend verwendet werden. Die Verfahren in diesem Handbuch und die Aufkleber auf dem Gerät enthalten Warn- und Vorsichtshinweise.
- Seite 10 Barracuda 2LP Installation Guide, Rev. E persönliche Sicherheit noch die Leistung der Einheit gefährdet. Beachten Sie in jedem Fall die folgenden Warn-und Vorsichtshinweise: • Führen Sie alle Wartungsarbeiten entsprechend den Anweisungen in diesem Handbuch aus. • Beachten Sie alle Warn- und Vorsichtshinweise in diesem Handbuch.
- Seite 11 Betrieb in Übereinstimmung mit UL 1950, IEC950, EN60950, CSA C22.2 950 und VDE0805 vorgesehen. Seagate ist ständig bemüht, die Zulassungsfähigkeit von Seagate-Produkten im Rahmen der gegenwärtig Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
- Seite 12 Anforderungen der FCC oder ähnlicher nationaler Behörden für eigenständige Geräte. Technische Testergebnisse zu elektromagnetische Strahlung sind für Designer von Untersystemen auf Anfrage von der Seagate-Sicherheitsabteilung erhältlich. Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
-
Seite 13: Technical Support Services
Please contact your dealer for technical support and installation troubleshooting. Product technical support is available for all Seagate products by calling the SeaFAX™, SeaFONE™, SeaTDD™, or SeaBOARD™ services. These are toll calls if you dial from outside of the number’s local dialing area. - Seite 14 Technical support specialists are available from 8:00 to 5:00 . PST, Monday through Friday. Recorded technical information on selected Seagate products is provided while you are on hold. Recordings are acces- sible 24 hours a day, 7 days a week.
- Seite 15 Barracuda 2LP Installation Guide, Rev. E Location Modem number USA, Mexico, Latin America (408) 438-8771 England 44-62-847-8011 Germany 49-89-140-9331 Singapore 65-292-6973 Australia 61-2-756-2359 Canada (416) 856-5581 France 33-1-40-67-1034 Korea 82-2-556-7294 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
-
Seite 16: General Description
Barracuda 2LP Installation Guide, Rev. E General description Barracuda 2LP SCSI disc drives are high-speed, ran- dom-access digital-data storage devices. The drive is a component for installation in an enclosure designed for the drive. This is often a rack within the system or an external enclosure designed to house one or more disc drives or other peripheral units. - Seite 17 Barracuda 2LP Installation Guide, Rev. E Characteristics ST31250 ST32550 Interface Fast SCSI-2 Fast SCSI-2 Capacity Unformatted 1,205.3 Mbytes 2,541.3 Mbytes Formatted 1,020.9 Mbytes 2,147.4 Mbytes Recording Cylinders (user) 3,711 3,510 Read/write data heads 5 Servo heads Avg bytes/track 64,160 64,160 Seek time Average read 8.0 msec...
- Seite 18 Barracuda 2LP Installation Guide, Rev. E Can also be operated according to SCSI-1 protocol. Standard factory units are formatted as follows: 512 data bytes per sector 9 spare sectors per cylinder 1 cylinder at the innter track reserved for spares Not including on-board controller overhead.
- Seite 19 Barracuda 2LP Installation Guide, Rev. E DC power requirements Single-ended Differential + + + + + 5V + + + + + 12V + + + + + 5V + + + + + 12V ± ± ± ± ± 5% ±...
- Seite 20 Barracuda 2LP Installation Guide, Rev. E Measured with an average reading DC ammeter. Instanta- neous +12V current peaks will exceed these values. A −10% tolerance is permissible during initial start of the spindle but must return to ±5% before reaching 7,200 RPM. The ±5% must be maintained after the drive signifies that its power-up sequence has been completed and that the drive is able to accept selection by the host initiator.
- Seite 21 Barracuda 2LP Installation Guide, Rev. E No terminator power. See Section 11.7.3.4 in the Barra- cuda 2LP Product Manual. All power-saving features are enabled (ASA II code only). Seeking is defined as a third-stroke seek at OD. The com- mand is issued every 20 msec. Read track is defined as repeat reads of track 15 with a 78% duty cycle on N models, 32% duty cycle on W models, 48% duty cycle on WC models, 60% duty cycle...
-
Seite 22: Initial Setup Information
Barracuda 2LP Installation Guide, Rev. E Initial setup information The general information beginning on this page applies to all of the Barracuda 2LP drive models. After reading the general information topics, refer to the appropriate drive- specific section listed below for additional information about configuring and installing your particular model. - Seite 23 Barracuda 2LP Installation Guide, Rev. E *This mounting procedure does not apply to WC or DC model drives. To mount a WC or DC drive, plug the drive into the system's single connector attachment (SCA) position on the system's back panel. SCSI ID jumpers Each device on the SCSI chain must have a unique SCSI ID.
- Seite 24 Barracuda 2LP Installation Guide, Rev. E Also check your system or controller user’s manual to ensure that you have not violated its SCSI ID numbering recommendations. Drive termination If you are installing a Barracuda 2LP drive in a system that has other SCSI devices installed, terminate only the end devices on the SCSI chain.
- Seite 25 Barracuda 2LP Installation Guide, Rev. E For information about how to terminate your drive, refer to the appropriate drive-specific section. Terminator power You usually will not need to change this option and can normally leave the drive configured as it was shipped from the factory.
- Seite 26 Barracuda 2LP Installation Guide, Rev. E Providing adequate cooling The enclosure design must ensure adequate cooling for the drive. The maximum ambient temperature is 50 The drive’s product manual (83328930) describes how to evaluate the air-flow design. The evaluation consists of ensuring that the case temperatures of certain critical components remain within acceptable limits during drive operation.
-
Seite 27: Kühlung Des Systems
Barracuda 2LP Installation Guide, Rev. E Kühlung des Systems Die Gehäusekonstruktion muß eine ausreichende Kühlung des Laufwerkes gewährleisten. Die Umgebungstemperatur darf maximal 50 C betragen. Die Produkthandbuch Barracuda 2LP (Dokument 83328930) enthalten Anweisungen zur Beurteilung der Luftstromkonstruktion. Die Beurteilung muß sicherstellen, daß... - Seite 28 Barracuda 2LP Installation Guide, Rev. E Above unit Über der Einheit Note. Air flows in the direction shown (back to front) or in reverse direction (front to back) Under unit Hinweis. Luftstrom in der angezeigten Richtung Unter der Einheit (von vorne nach hinten) oder in umgekehrter Richtung (von hinten nach vorne) Above unit Über der Einheit...
- Seite 29 Barracuda 2LP Installation Guide, Rev. E Mounting the drive and connecting cables Do not touch the connector pins or any components on the control board without observing static-discharge pre- cautions. Always handle the drive by the frame only. The drive may be mounted in any orientation (horizon- tally, vertically, and any combination thereof);...
- Seite 30 Barracuda 2LP Installation Guide, Rev. E Installation des Laufwerkes und Anschluß der Kabel Beachten Sie beim Handhaben und Anfassen der A n s c h l u ß s t i f t e u n d K o m p o n e n t e n d i e Vorsichtsmaßnahmen zur Verhinderung statischer Aufladung.
- Seite 31 Barracuda 2LP Installation Guide, Rev. E 2. Verify that all connections between the drive and the host system are correctly installed. 2. Prüfen Sie, ob alle Verbindungen zwischen dem Laufwerk und dem Host-System korrekt hergestellt sind. 3. Verify that you have correctly installed jumpers. 3.
- Seite 32 Barracuda 2LP Installation Guide, Rev. E Das Laufwerk wird über einen 4-poligen, neben dem SCSI-Anschluß befestigten Steckverbinder mit Gleichstrom versorgt. Der Ausgang eines Netzteils muß SELV (safety extra low voltage) nach IEC 950 entsprechen. Abbildung 4 zeigt die Steckerbelegung für den Gleichstromanschluß. Zum Anschluß des Gleichstromkabels an das Laufwerk das Kabelende in den Gleichstromanschluß...
- Seite 33 Barracuda 2LP Installation Guide, Rev. E Note. Signal ground on the power control board (PCB) and the head and disc assembly (HDA) are con- nected together in this drive and you cannot sepa- rate them. The equipment in which you have mounted the drive is connected directly to the HDA and PCB without electrically isolating shock mounts.
- Seite 34 Barracuda 2LP Installation Guide, Rev. E Systemgehäuse nicht an die HDA/PCB-Erdung anschließen wollen, müssen Sie das Laufwerk auf nichtleitende Weise (galvanisch isoliert) im Host- System einbauen. Die daraus u.U. resultierende verstärkte elektromagnetische Strahlung fällt in den Zuständigkeitsbereich des Systemdesigners. 5. Replace the host system’s cover. 5.
- Seite 35 If you want to enable the write cache, refer to your system’s drive controller and software utility documenta- tion. Seagate provides an ASPI utility that you can use in a PC compatible system to enable the write cache. It is available on Seagate’s CompuServe forum and on the...
- Seite 36 Barracuda 2LP Installation Guide, Rev. E N/ND drives Setting the SCSI ID jumpers Use the J4 connector to set the SCSI ID (see Figure 5). To change the SCSI ID, install jumpers on the appropriate pins as shown in the illustration. (front view of J4) Pin 1 Pin 2...
- Seite 37 Barracuda 2LP Installation Guide, Rev. E N/ND drives Terminating the drive ST31250N and ST32550N drives are terminated with permanently mounted IC active terminators. If you install one of these drives and it is not on the end of the SCSI bus, disable the terminators by removing the jumper from pins 5 and 6 of connector J1 (see Figure 6).
- Seite 38 Barracuda 2LP Installation Guide, Rev. E N/ND drives Terminator power There are four possible terminator power configurations for ST31250N and ST32550N drives (see Figure 7). You will not normally need to change this option and can leave the drive configured as it was shipped from the factory. ST31250ND and ST32550ND drives should be config- ured with a jumper connecting J1 pins 1 and 3 (and no jumper on J1 pins 2 and 4) as illustrated in Figure 7.
- Seite 39 Barracuda 2LP Installation Guide, Rev. E N/ND drives Synchronizing spindles Use pins 5 and 6 on the J4 connector to attach the spindle sync cable. See Figure 8. Pin 1 (front view of J4) Pin 1 Pin 2 Pin 1 Spindle sync Spindle Sync Reference cable connector...
- Seite 40 Barracuda 2LP Installation Guide, Rev. E N/ND drives Other applicable jumper options Several other jumper options are available as illustrated. Pin 2 Pin 1 Reserved Parity Check option Pin 1 Enable parity check of SCSI bus (default). Disable parity check. Write Protect option Write protect = Off (enables writing –...
- Seite 41 Barracuda 2LP Installation Guide, Rev. E W/WD drives Setting the SCSI ID jumpers Use the J5 connector to set the SCSI ID (Figure 10). To change the SCSI ID, install jumpers on the appropriate pins as shown in the illustration. SCSI I/O DC Power Connector...
- Seite 42 Barracuda 2LP Installation Guide, Rev. E W/WD drives Terminating the drive ST31250W and ST32550W drives are terminated with permanently mounted IC active terminators. If you install one of these drives and it is not on the end of the SCSI bus, disable the terminators by removing the jumper from pins 5 and 6 of connector J1.
- Seite 43 Barracuda 2LP Installation Guide, Rev. E W/WD drives Terminator power There are four possible terminator power configurations for ST31250W and ST32550W drives (see Figure 12). You will not normally need to change this option and can leave the drive configured as it was shipped from the factory.
- Seite 44 Barracuda 2LP Installation Guide, Rev. E W/WD drives Synchronizing spindles Use pins 11 and 12 on the J5 connector to attach the spindle sync cable. See Figure 13. SCSI I/O DC Power Connector Pin 1 Pin 1 Connector 3P 2P Spindle Sync Reference Spindle sync cable connector...
- Seite 45 Barracuda 2LP Installation Guide, Rev. E W/WD drives Other applicable jumper options Other option jumpers are available as illustrated below. Pin 1 Pin 2 Pin 1 Reserved Parity Check option Enable parity check of SCSI bus (default). Disable parity check. Write Protect option Write protect = Off (enables writing –...
- Seite 46 Barracuda 2LP Installation Guide, Rev. E W/WD drives Pin 1 SCSI I/O Connector Pin 1 Pin 1 GND (cathode) Remote unit active LED connector POS (anode) Pin 1 (front view of J4) Pin 2 Pin 1 SCSI ID = 0 Fault LED pin (+) SCSI ID = 1 Vendor Unique...
- Seite 47 Barracuda 2LP Installation Guide, Rev. E WC/DC drives Setting the SCSI ID jumpers The SCSI ID for WC drives is normally set over the SCSI bus by the host system using connector contacts 39 (ID0), 40 (ID2), 79 (ID1), and 80 (ID3). Systems design- ers may, optionally, install a remote operator panel con- nection to set the SCSI ID.
- Seite 48 Barracuda 2LP Installation Guide, Rev. E WC/DC drives Applicable jumper options Option jumpers are available as illustrated below. Pin 1 Pin 2 Pin 1 Reserved Parity Check option Enable parity check of SCSI bus (default). Disable parity check. Write Protect option Write protect = Off (enables writing –...
- Seite 49 Barracuda 2LP Installation Guide, Rev. E WC/DC drives Pin 1 Pin 1 (front view of J4) Pin 2 Pin 1 SCSI ID = 0 Fault LED pin (–) SCSI ID = 1 Vendor Unique SCSI ID = 2 SSREF (+) SCSI ID = 3 Unit Active LED pin (–) Not used...
- Seite 50 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
- Seite 51 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
- Seite 52 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
- Seite 53 Seagate Technology, Inc. 920 Disc Drive, Scotts Valley, CA 95066-4544, USA Publication Number: 83328920, Rev. E, Printed in USA Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
