BOX CONTENTS

ARC3
IEC Power Cable
Quickstart Guide
Safety & Warranty Information Booklet
REGISTRATION
Please go to http://www.numark.com to register your ARC3. Registering your product ensures that we can
keep you up-to-date with any last-minute product developments and provide you with world-class technical
support, should you run into any problems.
GROUND RULES
1. Make sure all items listed in the BOX CONTENTS section are included in the box.
2. READ SAFETY & WARRANTY INFORMATION BOOKLET BEFORE USING THE PRODUCT.
3. Study the connection diagram in this guide.
4. Place mixer in an appropriate position for operation.
5. Make sure all devices are turned off and all faders and gain knobs are set to "zero"
6. Connect all stereo input sources as indicated in the diagram.
7. Connect the stereo outputs to power amplifier(s), tape decks, and/or other audio sources.
8. Plug all devices into AC power.
9. Switch everything on in the following order.
•
audio input sources (i.e. turntables, CD players, etc.)
•
mixer
•
last, any amplifiers or output devices
10. When turning off, always reverse this operation by,
•
turning off amplifiers
•
mixer
•
last, any input devices

CONNECTION DIAGRAM

CD PLAYER
LINE OUT
FADER START CABLE
AUDIO CABLE
RELAY CABLE
MIXER
LINE IN
AUDIO CABLE
POWER SUPPLY
1
CD PLAYER
LINE OUT
FADER START
CABLE
