4. Screw the pins to the frame and the insert the wheels into the pin with a hammer tap.
DETAIL B

TECHNICAL DATA

Measurement
Max capacity
WARNINGS!
- Check the locking nuts are tightened.
- Observe the maximum fl ow rates indicated in the data sheets.
- Avoid direct contact with open wounds.
- Not for use in open environments.
ENGLISH
Weight
Trolley 47x41 h 83 cm
Shelf: 40 x 30 cm
Box: 94,5x10x46
11,3 kg (12,5 with box)
40 kg
Avvitare i perni nel lato
inferiore della struttura
/ Screw the pins on
the lower side of the
structure.
Inserire le ruote nel
perno con un colpetto
di materllo / Insert the
wheels into the pin
with a hammer tap
