Description
Click-on ratchet head for torque wrench
Teflon spray
Carrying belt
Carrying back pack
Carrying case
Set of pulling attachments
Set of pulling chains
4

Preparation for first use

4.1 General
Check the equipment for completeness and damage. Do not use the equipment if it is damaged; in that
case contact the Holmatro dealer.
5

Operation

5.1 System operation
5.1.1 General
The HCT is a tool where the hydraulic pump is integrated in the tool. The hydraulic pump is driven by a
pump handle. This pump displaces hydraulic oil and is capable of building up pressure. The hydraulic
pump is connected directly to the hydraulic cylinder.
The hydraulic cylinder contains a piston that can move axially. If the cylinder is pumped full from the
bottom, pressure builds up beneath the piston so that it is pushed to the outside. If the cylinder is
pumped full from the top, the piston is forced back into the cylinder.
In tools like cutters, spreaders and combi tools the axial movement of the piston starts a mechanism
that then makes a cutting or spreading movement.
5.2 Fitting the pump handle (Fig. 2 & 4)
• Move the pump handle locking ring (3) towards the pump handle (1).
• Place the pump handle parallel to the pump rod holder (4).
• Release the locking ring and let it fall into the pump rod holder.
• Place the pump rod in the correct position with regard to the blades by using the pump handle
adjustment knob (8).
5.3 Folding the carrying handle (Fig. 2 & 4)
• Move the carrying handle locking bar (5) upwards (2).
• Fold the carrying handle close to a preferred position, release the locking bar (5) and rotate the
carrying handle until it locks.
5.4 Rotating the carrying handle (Fig. 2 & 4)
• Push the carrying handle locking knob (6) inwards.
• Rotate the carrying handle close to a preferred position, release the locking knob (6) and rotate the
carrying handle until it locks.
HCT5111 (RH)(ST)/HCT5117 (RH)(ST) 916.001.234_004
HCT5111 (ST)
150.581.672
150.581.095
150.582.506
150.553.155
150.182.228
N.A.
N.A.
EN
HCT5117 (ST)
150.182.241
150.582.548
