D- USING

D1-1- SETTINGS
1
D1-2- CALL FROM THE OUTDOOR STATION
1
3
Automatic
gate opening
control 4
12 EN
2
Brightness
BRT. 8
Contrast
CON. 15
Colour
COL. 18
Voice volume
CALL. 4
Melody volume control
INCOME. 2
Set the ring melody
RING. 7
or +
Setting Switch from a setting
item to another
2
Answer a call
Or
Strike
control
End a call
D1-3- INTERCOM FUNCTION
You can connect up to 3 monitors to the same outdoor station and talk to another monitor.
1
Monitor 1
ROOM CALL.
Monitor 1 or 2
2

E- TECHNICAL FEATURES

Indoor monitor
Power supply
Screen
LCD resolution
Outdoor station
Material
Lighting
Operation temperature
Angle view
Protection rating
Adapter
Power supply
Monitor 2
Call
ROOM CALL.
End a call
AC 230V / 50Hz
DC 13,5V / 0,8A
7 inch digital TFT LCD
800 x 480 pixels
Aluminium front
LED for night vision
-5 ~ 50°C
90°
IP44
Input 100-240V 50/60Hz 0,3A
Output DC 13,5V 0,8A
Answer a call
EN
13
