INSTALLATION AND OPERATING CONDITIONS OF THE APPLIANCE
Installation before using the applian-
ce for the first time
1. Take the product out of the package, re-
move the scotch tapes protecting the door
and the equipment. The possibly remaining
adhesive stains may be removed with a mild
washing agent.
2. Do not throw away the polystyrene ele-
ments of the packaging. In the case of the
necessity to transport the fridge-freezer,
pack it in the polystyrene elements and film,
as well as protect it with a scotch tape.
3. Clean the interior surface of the fridge-
freezer and the elements of the equipment
with a washing agent dissolved in lukewarm
water, then wipe it dry.
4. Place the fridge-freezer on an even, flat and
stable surface, in dry, aired and shadowy
room, far from the heat sources such as
an oven, cooktop, central heating radiator,
central heating pipe, hot water installation,
etc.
Minimal distances from the heat
sources
- from the electric gas and other ovens
- 30 mm,
- from oil or coal fired ovens - 300
mm,
- from in-built ovens - 50 mm
If there is no possibility to ensure the above-
mentioned distances, provide an appropria-
te insulation board.
5. Make sure the appliance is placed in the
horizontal position by screwing in 2 adju-
stable front legs (fig. 2)
6. In order to ensure easy opening of the
door, the distance between the side
wall of the appliance (from the side of
the door hinges), and the wall should
amount to: 70 mm (for FD224.3) i 50 mm
(fir FD204.3)
7. Ensure adequate ventilation of the room
and free air circulation from all sides of
the appliance (fig. 3).
The rear wall of the refrigerator, in
particular, the condenser and other
elements of the cooling system may
not contact other elements, which
may damage them, (e.g. central
heating pipe and the water supply
pipe).
52
min 30 mm
condensator
