Figure 4: Rail ends attach to the outside of each post
Rail ends attach on the
outside of the front and
rear rack posts
3. Place the FileCruiser onto the rails.
At least two persons are required to safely lift the system.
Lift the FileCruiser itself. Do not lift the system by its brackets.
Figure 5: Placing the FileCruiser system onto the rack rails
Brackets
FileCruiser VA2600 Hardware Installation Guide
Rails installed
and tightened
9
FileCruiser system
