nedis ALRMMW30WT Beschreibung

ALRMMW30WT
Wall alarm with remote control
Description
The wall alarm is a battery-powered security device which is mounted to the wall.
1. PIR motion detector
2. LED indicator
3. Mode selection switch
4. Battery compartment
5. Learning button
6. Mounting bracket
7. Remote control
8. Arming button
9. Disarming button
10. Battery compartment
11. Alarm / Chime selector
Installation
• Mount the detector in a location where the remote control has a clear line of sight to the detector.
• Mount the detector to the wall at a height between 1.8 and 2.4 metres.
• Do not install the device outdoors.
• Do not install the device in direct sunlight.
• Do not install the device in locations with high humidity, such as bathrooms and swimming pools.
• Do not install the device within detection range of devices which emit heat or cold (e.g. air conditioners, refrigerators, ovens, heaters, microwaves or other
electronic equipment which generates heat as a by-product of operation).
• Install the mounting bracket to the wall using the supplied screws.
• Secure the detector to the mounting bracket.
Use
Alarm mode
If the detector is triggered in alarm mode, the alarm will sound with a 30-second delay. If the detector is not disarmed within 30 seconds, the alarm will sound at full
volume. To disarm the detector, press the disarming button on the remote control.
1
3
2
7
Notes:
• The effective detection range depends on the height and may vary in different environmental conditions.
• Any obstructions in the environment will reduce the detector's effectiveness.
• Small animals can trigger the detector.
• Use the switch to select the mode (alarm mode / chime mode).
If the battery level is low, the LED indicator will flash slowly to indicate that the batteries must be replaced immediately.
• Open the battery compartment.
• Insert the batteries (3x AA) into the battery compartment.
• Close the battery compartment.
• To pair the remote control with the detector, use a screwdriver to press the learning button. Aim the remote control at
the front of the detector. The LED indicator flashes slowly to indicate that the detector is in learning mode.
• Press a button on the remote control. The detector will beep to indicate that the pairing is succesful.
• Press the button to arm the detector.
• Press the button to disarm the detector.
• Open the battery compartment.
• Insert the battery (CR2032) into the battery compartment.
• Close the battery compartment.
6
8
9
10 11
5
4
English
