Check Items Shipped with the Router
Figure 1-1 Items Shipped with the Router
1 Yellow Ethernet cable
2
Lavender ADSL cable
3 Power supply
Step 2 Check which ADSL cable was shipped with the router. The router is shipped with
one ADSL cable, specified when the router was ordered: a standard
straight-through RJ-11-to-RJ-11 ADSL cable, a crossover RJ-11-to-RJ-11, or a
straight-through RJ-11-to-RJ-45 cable.
Locate the product serial number.
Step 3
The serial number label for the Cisco SB 106 is located on the rear of the chassis,
at the left edge
Cisco SB 106 Router Cabling and Setup
1-4
Chapter 1
4 Power cord
5
Power lock clip
6 Product documentation
(Figure 1-2).
