Storage, transport

Storage
DANGER! Risk of injury! Make sure that
unauthorized persons do not have access
to the device!
• Store the device in a dry place.
• Before each storage, the catch-sack must be
cleaned.
Transport
• Secure the device against slipping.
• If possible, use the original packaging for dis-
patching.
Fault/malfunction
Motor not running.
Vacuum result is not suffi-
cient.
If you can't fix the fault yourself, contact your nearest
vendor. Please be aware that any improper repairs
will also invalidate the warranty and additional costs
may be incurred.
Disposal
Disposal of the appliance
Appliances which are labelled with the adja-
cent symbol must not be disposed of in
household waste. You must dispose of such
old electrical and electronic equipment sep-
arately.
– Please check with your local authority about the
possibilities for correct disposal.
Through separate disposal you send old equipment
for recycling or for other forms of re-use. You will
thus help to avoid in some cases that damaging
material gets into the environment.
Disposal of the packaging
The packaging consists of cardboard and
correspondingly marked plastics that can
be recycled.
– Make these materials available for
recycling.

Technical data

Item number
Nominal voltage
Nominal output
Protection class
RPM
max. blow speed
Noise pressure level (L )*
PA
Sound power level (L )*
WA

Faults and remedial measures

When something isn't working...
Malfunctions are often caused by minor faults. You
can easily remedy most of these yourself. Please
consult the following table before contacting the
vendor. You will save yourself a lot of trouble and
possibly money too.
Cause
No mains voltage?
Cable faulty?
Collecting sack full?
Suction speed too low?
Product clogged?
Item number
Vibration**
Weight
Bag content
Mulch ratio
*)
**) The specified vibration emission value was measured in
115 158
230–240 V~, 50 Hz
2800 W
II
−1
8000–13000 min
250 km/h
93 dB(A)
(K = 3 dB(A))
104 dB(A)
(K = 3 dB(A))
DANGER! Risk of injury! Improperly per-
formed repairs can lead to the device not
functioning safely. This endangers yourself
and your environment.
Remedial measure
Check cable, plug, socket and fuse.
Contact your local vendor.
Empty collecting sack (► Removing
the collecting sack – p. 22).
► Setting the blower or vacuum
speed – p. 22
► Rectify clogging – p. 22
The specified values are emission values and do not necessar-
ily represent safe workplace values. Although there is a corre-
lation between emission and immission levels, this cannot be
used to infer whether additional safety measures are necessary
or not. Factors which affect the current immission levels at the
workplace, include the type of room, other sources of noise,
e. g. the number of machines operating and other processes
taking place in the vicinity. Permitted workplace values can dif-
fer from country to country. This information is designed to help
the user to better assess the dangers and risks. Determination
of noise emission values in accordance with EN 60745-1.
accordance with a normed test procedure and can be used in
order to compare one tool with another. The specified vibration
emission value can also be used for an introductory evaluation
of the exposure. The vibration emission value may fluctuate
from the specified value during actual use of the power tool.
These fluctuations will depend on the way in which the power
tool is used. Try to keep vibrations to a minimum. One method
of reducing the vibration load is, for example, limiting the length
of time you work with the tool. All parts of the operating cycle
must be taken into account for this purpose (for example, also
including times in which the power tool is switched off and
times in which it is switched on, but is running without load).
Determination of vibration emission values in accordance with
EN 60745-1.
GB
115 158
< 4,31 m/s²
(K = 1,5 m/s²)
4,8 kg
50 l
6:1
