axing EoC 10-01 premium-line Schnellstartanleitung Seite 3

Safety advices:
 Do NOT use the device near water or in rooms with high humidity such
as humid cellars or near swimming pools.
 Do NOT use the device outdoors. All connections must be located inside
a building.
 Keep the device away from moisture, dust or corrosive liquids.
 Do NOT install the device, use it or perform maintenance during a thun-
derstorm. There is a risk of electric shock during thunderstorm.
 Connect ONLY appropriate accessories to the device.
 Make sure that all cables are connected to the correct port.
 Carefully lay the Ethernet, antenna and electric cables to ensure that
nobody can step on or stumble over them.
 Do NOT cover the ventilation slots of the device since insufficient air
supply may result in damage to the device.
 Do NOT place any objects on the device. Position the device in a place
where NOBODY can step on it.
 Prior to maintenance or dismounting work, disconnect the Ethernet and
electric cable from the device.
 In case of damage, interrupt the power supply.
 Do NOT try to repair the device. Contact your local retailer to order a
new device.
 Do NOT open the device or unit. Opening the device or removing its
covers causes risks, for example due to high voltage. This device should
ONLY be repaired or uninstalled by qualified service.
State of the art 2019-03-11
Technical improvements, changes in design, printing- and other errors expected.
Technical data:
Typ EOC01001
Frequency range 5...1218 MHz
Connectors (TV | EoC) 2 × F female
Frequency range TV bypass 85...1218 MHz
Frequency range transmission 5...65 MHz
Maximum allowed attenuation in 80 dB
coax network
Data rate (gross) 720 Mbps
EoC standard ITU-T G.9960/G.9961 G.hn over Coax
Ethernet standards IEEE 802.3u 100BaseT Fast Ethernet
IEEE 802.3ab 1000BaseT Gigabit
Ethernet
WiFi IEEE 802.11b/g/n
Connectors (LAN) 2 × RJ 45
Data interface 100 | 1000 Mbps
Number of devices in EoC network 1 × EoC 10-01 | ≤ 31 EoC 10-02
Operation voltage 12 VDC
Power consumption <5 W
Operation voltage over Coax 60 VAC +/- 20%
Operation voltage over LAN (PoE) 37~57 V
External switching power supply 100...240 V~/50/60Hz | 12 V=/1 A
Ambient temperature range (acc. to 0°C...40°C
EN 60065)
Dimensions (W × H × D) appr. 178 x 136 x 35 mm
Herewith AXING AG declares that the marked products comply with the valid
guidelines. You can call up the complete EU declaration of conformity for
download by entering the article in the search field at www.axing.com.
WEEE Nr. DE26869279 | Electrical and electronic components must not be
disposed of as residual waste, it must be disposed of separately.
Manufacturer EEA contact address
AXING AG Bechler GmbH
Gewerbehaus Moskau Am Rebberg 44
8262 Ramsen 78239 Rielasingen
EoC 10-01
premium-line
Ethernet over Coax
Master
Quick start guide
