3. Meaning of pictograms
1. Caution – rotating tool
2. Caution – refer to the operating instructions
4. Technical data
Engine
Engine rating
Working width
Cultivating blade set/diameter
Forward gears
Starting system
Fuel Unleaded standard grade petrol
Engine oil
5. To assemble the power cultivator
Secure the handle bracket (2) as shown in Figure 3.
The Bowden cable (B) for the clutch must be posi-
tioned on the top of the rear of the bracket (Figure
4). The height of the handle bracket (Figure 9) can
be adjusted using the screws (A).
To give the machine better stability, insert the
depth stop (5) straight away and secure it with the
split pin (6) (Figure 11).
Attach the Bowden cable (B) to the top hole in the
clutch lever (I) as shown in Figure 7.
Undo the hexagonal nut (G) on the Bowden cable
adjusting screw and insert the adjusting screw into
the mounting loop (H) and secure it with a hexago-
nal nut (G) (Figure 8). The adjusting screw should
be at the rear of the thread and should not be furt-
her forward than the middle. If the clutch lever (I) is
pressed down fully when the engine is running, the
cultivator blades should turn. If the cultivator bla-
des do not turn properly, it means that the engine
mounting has not been tensioned tightly enough
against the V-belt and in this case the adjusting
screw (X) can be undone further in the direction
indicated by the arrow (Figure 8). This creates grea-
ter tension on the V-belt.
Secure the Bowden cable tube from the accelerator
lever to the machine frame using the cable ties (4),
Figure 5.
6. To start the machine
For safety reasons the machine is delivered without
any petrol or engine oil inside it.
First add the oil. Unscrew the oil dipstick (J) from
the oil filler neck and fill the oil sump with engine
oil grade 10W40 (approx. 0.6 liters) until the level
reaches the "max" mark on the dipstick (J) (Figure
12).
29.03.2007
Fill the petrol tank with standard grade unleaded
petrol.
Set the depth top (5) to the correct height and
secure it with the split pin (Figure 11).
Swing the transport wheel upwards and engage it
with the spring (Figure 10).
Set the petrol cock (F) to "ON" (Figure 6).
4-stroke
Set the starter lever to position –a- (Figure 13).
Pull the starting cable gently until you feel resi-
3 kW / 4.1 bhp
stance then pull it hard. If the engine does not start
36 cm
straight away, repeat the starting routine.
2 sets L+R / 26 cm
Starting lever in position -b- = Idling
1
Starting lever in position -c- = Stop engine
You can adjust the complete handle bracket to suit
Reversing device
your body size. To do this undo the screws
-A- in Figure 9, adjust the bracket and tighten the
Approx. 0.6 liters
screws again.
To start work, push the starting lever further in
direction -a- to suit the soil conditions.
To start the cultivator blades, simply push the
clutch lever (I) downwards and hold it there (Figure
7). When you release the clutch lever the cultivator
blades will stop.
7. Servicing
Only use genuine spare parts.
Dispose of oil and petrol in the places provided for
them.
Spare spark plugs:
For example Bosch WR 7DC or Denso W16EPR-U

8. Ordering replacement parts

Please quote the following details when ordering repla-
cement parts:
Type of machine
Article number of the machine
Serial number of the machine
Replacement part number of the part you require
(Refer to the replacement parts list)
For our latest prices and information please go to
www.isc-gmbh.info
