• Identification of the supply grid type (TN system,
IT system, TT system) and the resulting connection
conditions
(conventional
earthing, safety earthing, additional measures
required etc.).
Commissioning
1 Switch off the house circuit breaker in the circuit.
2 Remove all plastic components and the existing
switch, if any.
3 Make a note of the serial number located under-
neath the barcode.
4 Connect the switched external conductors of ter-
minals 1 and 2 to the motor as follows:
Terminal 1 – down; Terminal 2 – up
5 Connect the external conductor to terminal L.
6 Connect the neutral conductor to terminal N.
7 Attach the inwall roller shutter controller to the
inwall box using the enclosed screws.
8 Hold the frame on the inwall roller shutter control-
ler and attach the latter by pushing on the approp-
riate rocker adapter.
9 Switch the house circuit breaker in the circuit back
on.
10 Integrate the inwall roller shutter controller in the
system.
11 Fit the rocker.
General information
eQ-3 Entwicklung GmbH hereby declares that this
device meets the basic requirements and the other
relevant regulations laid down in Directive 1999/5/
EC.
You can find the complete declaration of conformity
at:
www.eq-3.de/rwe-smarthome
eQ-3 Entwicklung GmbH,
Maiburger Str. 36,
D-26789 Leer
protective
multiple
Technical data
Name of device
Supply voltage
Standby consumption
Radio frequency
Max. transmission
power
Receiver class
Max. switching power
Switching capacity
Protection class
Protection category
Ambient temperature
Dimensions
Weight
Technical changes reserved.
Information about disposal
Do not dispose of the device in the house-
hold waste! Electronic devices are to be dis-
posed of via the local collection points for
old electronic devices in accordance with
the Waste Electrical and Electronic Equip-
ment Directive.
5
ISR2
230V/50Hz
0.5W
868.3MHz
10mW
SRD Class 2
230VA (motor load)
1A (motor load)
IP20
II
+5°C to +35°C
71x71x37mm (WxHxD)
43g
