• Do not use the appliance in damp rooms!
• Never use without the filter. Check that the filter is inserted cor-
rectly!
• Keep hair, clothing and body parts away from the vacuum nozzle
during use!
• Keep the vacuum cleaner away from sources of heat like radia-
tors, ovens, etc.!

Unpacking the Appliance

1. Remove the appliance from its packaging.
2. Remove both protection parts from the bottom of the
appliance.
3. Check the delivery scope for completeness.
4. Check the appliance for any transport damage, in order
to prevent hazards.
NOTE:
In case of any transport damage, contact your dealer
immediately. Do not use a damaged appliance!

Overview of the Components /

Scope of Delivery
1 Air slide
2 Handle
3 Suction hose
4 Hose connection
5 On / off switch
6 Carrying handle
7 Dust collector release button
8 Cable-winding button
9 Suction power control
10 Ventilation grill lock (outlet filter)
11 Positioning aid
12 Dust container
13 Dust collector base plate
14 Connection head of the vacuum hose
15 Carpet / hard floor selector
16 Floor nozzle (with hook (not shown))
17 Telescopic suction tube
18 Parquet brush
19 Combined crevice and brush nozzl
Start-up
• Insert the connection head of the suction hose into the
hose connection of the appliance. Tighten the connection
header anticlockwise.
• To release the hose again, turn the connecting header
clockwise.
PC-BS3039_IM
• Insert the vacuum tube into the handle if required.
• Then assemble the floor nozzle and / or the accessories.
To detach the nozzle attachments from the suction pipe,
pull them off by turning them slightly.
Nozzle Attachments
Floor Nozzle (16)
The floor nozzle features castors for easier movement.
You can clean smooth surfaces and carpets with the floor
nozzle.
• Adjust the brushes outwards or inwards using the
lever (15).
Best use of the appliance depends on the texture of the
floor covering. We recommend the following use:
• Use without brushes:
For vacuuming floor coverings
with a deep pile
• Use with brushes:
For vacuuming smooth floors
and carpets with a shallow pile
Parquet Brush (18)
For gentle cleaning of sensitive hard floors like parquet,
laminate, tiles, etc.
Crevice and Brush Nozzle (19)
NOTE: Folding "2 in 1" nozzle
When this is folded together it can be used as a groove
nozzle. If you would like to use the brush nozzle, pull the
brush section in the direction of the arrow until it locks in
place.
