Please unfold page 3. Then you can always see the oper-
GB
ating elements and connections described.

1 Operating Elements and Connections

1 Mounting plate for the camera
2 Setscrew for setting the tilting angle (max. 90°) of the
mounting plate (1)
3 Free positionable limiting clip to adjust the panning range
4 Switching device to change the turning direction
5 Reversing switch for the turning direction
6 BNC-plug for connection to the video output of the camera
7 Thread (6,3 mm/
mounting the pan head
8 BNC output jack for the video signal of the camera:
connection to the video input of the monitor via a 75 Ω
cable
9 Cable with four control leads to connect the pan head to
the control device
red:
yellow: clockwise panning
white:
black:

2 Safety Notes

This device is in accordance with EC-directive 89/336/EEC
for electromagnetic compatibility.
The device is suitable for indoor use only. Protect it from hu-
midity and heat (admissible ambient temperature 0–40 °C).
For cleaning use a dry, soft cloth only. Do not use chemicals
or water.
To avoid damages on the pan head, pan the device only
electrically (i. e. via the control leads). Do not pan it manually!
If the device is used for purposes other than originally in-
tended or if it is wrongly connected, wrongly operated or not
8
1
/ ") at the bottom side of the device for
4
automatic panning
counter-clockwise panning
ground (common connection)
