SATA Quick Clone Dock • Quick Install Guide
Thank you for purchasing the MANHATTAN
This guide presents the basic steps for using this device. For detailed operating and
cloning instructions and specifications, refer to the user manual available at
www.manhattan-products.com.
Basic Setup & Offline Operation
1. Use the included power adapter to
connect the DC Input jack to an AC
power outlet.
2. Insert the source HDD in Bay A and
the target HDD in Bay B. CAUTION:
The capacity of the target HDD must
be greater than the source
HDD. Any data already on
the target HDD will be lost.
3. When the A and B LEDs
light, set Power to On.
4. Press the Clone button for 3
seconds. When the LED lights,
press the Clone button again. The
LEDs indicate progress (25-100%).
All the LEDs light when complete.
5. Turn the power off; remove the
drives.
USB Operation
The software on the included CD needs
to be installed to use the Dock with
your PC. NOTE: This is PC-based
software.
1. Use the included power adapter to
connect the DC Input jack of the Dock to an AC power outlet.
2. Use the included USB cable to connect the Dock to the computer.
3. Insert an HDD (2.5" or 3.5") firmly into the Dock.
4. Toggle the Power switch to On and confirm that the Power LED lights.
5. Insert the CD and follow the on-screen instructions or refer to the user manual.
2
ENGLISH
SATA Quick Clone Dock, Model 130226.
®
POWER ON/OFF
DISK
POWER
DISK DISK
MASTER
POWER
MASTER SLAVE
English
Rear view: connections
USB DC INPUT
Front view: LED indicators
DISK 25% 50% 75% 100%
SLAVE
25% 50% 75% 100%
Top view: HDD bays
Bay A
(master/source)
Bay B
(slave/target)
Clone
button
