About Digi Connect ES Device Server

Digi Connect ES Device Server is a high performance, high-reliability serial-to-Ethernet concentrator with
extended safety characteristics.

Technical description

Digi Connect ES provides serial-over-Ethernet connectivity to connect sensitive RS-232-enabled devices to
the network. Both serial and Ethernet ports are galvanically isolated, and Ethernet ports offer 10/100 Mbps
network interface with an optional Ethernet switch.
Digi Connect ES is intended for data collection and information management, either directly or through
networks with independent devices. Digi Connect ES does not provide alarm or safety notification
capabilities and is not to be used in the critical path between any device and any alarm or safety notification
system.

Digi Connect ES Device Server models

This guide pertains to all Digi Connect ES Device Server models:
Base model
DC-ES-4SB
DC-ES-8SB
DC-ES-4SB-SW
DC-ES-8SB-SW
Digi Connect ES products are compliant with IEC 60601-1 3rd edition.
Digi Connect ES is intended for use as an ITE device for data transmission only. No data modification takes
place within the device.
Digi Connect ES Device Server Hardware setup guide
Regional
model variants
DC-ES-4SB-??
DC-ES-8SB-??
DC-ES-4SB-SW-??
DC-ES-8SB-SW-??
Description
Digi Connect ES 4SB (4 ports)
Digi Connect ES 8SB (8 ports)
Digi Connect ES 4SB with Switch (4 ports)
Digi Connect ES 8SB with Switch (8 ports)
