Connectors, LEDs, and controls

Callout
1
2
3
4
5
6
7
8
Digi Connect ES Device Server Hardware setup guide
This device contains no user-serviceable parts. No modification of this equipment is allowed.
In case of smoke, disconnect mains power from the device and discontinue use.
Do not use this device in areas with high magnetic fields.
Symbol
250V AH
Off On
100-240V
50 - 60 Hz, 0.2A MAX
l
Description
Fuse
Off/On
Mains power connector/Power input
Grounding stud
Ethernet uplink port
Reset switch
Ethernet switch ports
Ethernet uplink LED
Connectors, LEDs, and controls
