Connect each serial device to a serial port (13) on the Digi Connect ES Device Server. If the connection
between the device and the network is established, the serial port LED (10) illuminates.
CAUTION!
Ethernet Interface Ports
Serial Interface Ports
CAUTION!
WARNING!
WARNING!
WARNING!
WARNING!
6 Setup is complete:
• There are no operator controls on the device.
• Other than these instructions and the environmental limits listed in this guide, there are no additional
requirements for operator access or positioning of the device.
• No additional setup is required from the operator.
• Any additional required configuration is done remotely following the specific procedures that the
systems integrator supplies for use of this product with their software.
Digi Connect ES Device Server Hardware setup guide
Ethernet and serial interfaces both use RJ-45 connectors. Make sure to connect Ethernet
devices to an Ethernet interface and connect serial devices to a serial interface.
This equipment should be connected only to other equipment compliant with 60601 or 60950.
Cable assemblies are designed to prevent inadvertent disconnection.
Route cables to prevent tripping hazards.
Connect or disconnect each serial and Ethernet cable at both ends before connecting or
disconnecting another cable. Do not leave loose cables connected to the device.
WARNING: Do not touch other persons while connecting or disconnecting serial or Ethernet
devices to Connect ES.
Setting up Digi Connect ES hardware
