INCLUDED ACCESSORIES:

• Turntable Platter
• Dust Cover
• 2x Dustcover hinges
• Balance Counter Weight
• PHONO RCA Cable with earth lead
• AC power supply cord
• Rubber Mat
• Instruction Manual
• Ortofon 2M Red cartridge & headshell
2
15 16 17
DESIGNATION
1. Turntable
2. Hub
3. ON/OFF Button on Turntable Illumination
4. START/STOP Button
5. 33/45/78 Switch
6. Headshell incl. Ortofon 2M Red
7. Tone Arm
8. Tone Arm Ring
9. Tone Arm Rest
10. Tone Arm Lift
11. Anti-Skating Wheel
12. Tone Arm Ring Locking Mechanism
13. Counterweight Scale
14. Counterweight
15. Audio Output (Cinch)
16. Ground Screw (GND)
17. Voltage Selector Switch
18. Mains Cable Connection
19. Turntable Cover Mount
13
8
9
7
6
19
18
14
12
11
10
9
