The Dual Function Control Box is an electronic system developed to protect Harken
winches from overload.
Upon reaching the load set for the different operating speeds, the device intervenes
by cutting the power supply to the electric winch it is connected to, temporarily
interrupting its operation. The cut-off loads are factory set and differ according to
the winch capacity.
Two inputs equipped with MicroFit
winch, allowing installation of one or two Harken Digital Switch System (DSS)
buttons on different positions on the vessel, for example on the port and starboard
helm station. Alternatively, it is possible to connect standard buttons (BRS1 e
BRS2) to the supplied Faston connectors (see Installation layout).
N.B.: It is not possible to use both Digital Switch System and normal
buttons at the same time. If a digital button is connected, the standard
inputs are automatically disabled.
CAUTION! Pursuant to applicable regulations, the device is considered to
be a servo controller and NOT a safety device; as such, responsibility for
the manoeuvres performed via this device always lies with the operator.
CAUTION! The device must only be installed by specialised personnel.
The device is supplied together with all winches in the standard line in order to
guarantee greater efficiency, while specific models are available on request for the
other product lines.
As regards to installation layouts relating specific models, refer to the special
installation guide Dual Function Control Box on the web site www.harken.com.
CAUTION! Cut power off before proceeding with installation.
CAUTION! Each winch features its own Dual Function Control Box: check
the correct association before installation.
