General Overview

The charger is a fully Automatic/ Electronic On-board Marine Battery
Charger. ProMite is pre-wired for easy installation and is 100% waterproof for fresh
and salt water applications.
The Pro Sport Lt
fully automatic charging which includes a "Float " maintenance mode that is safe
for long and short term storage.
or over charging your batteries.
Easy to view LED indicators will provide you with AC Power On and Charging Status.
The LED Indicators can be seen from the front and side of the charger when
installed.
The Pro Sport is available in 2 models and can be used in 12 or 24 volt .
Please attach the DC output cable terminals as illustrated in the installation section of
this manual.

General Operation

Install your Pro |Sport Lt - Fully Automatic / Battery Charger to the
guidelines in this manual.
Make sure your charger and batteries are properly vented. Connect your extension
cord with no AC Power present to the charger and proceed to plug your extension
cord in at a nearby 230 v RCD (Ground Fault Circuit Interrupt) outlet.
With your charger plugged in properly, it will automatically charge your batteries
while it conditions and extends the life of your batteries.
always leave your charger plugged in to reduce sulfate buildup allowing your
batteries to be fully charged and maintained until their next use.
AC Power and Charging LED Status Indicators
The ProMite includes two LED indicators as shown below.
Green "AC Power" LED indicator:
When on, the green LED indicates when AC Power is present.
Red " Charging" LED indicator:
When on, the red LED indicates the charger is in its Automatic Charging Mode.
When charging is complete only the green LED will remain on.
Fully Automatic Charging Overview
When the Battery Charger is turned on the green
AC power indicator with turn on followed by the red charging LED indicator.
The Automatic Charger will provide the following:
Pro Sport Charging - Red and Green LED On
During this mode the charger will use its available charging amps (as controlled
by temperature) until battery voltage is raised to 14.1 VDC (safe for lead acid or
gel batteries).
Pro Sport Conditioning - Red and Green LED On
The ProSport will charge batteries to 14.1 VDC to complete charging while
conditioning batteries. Upon completion the ProMite will go to into its
maintenance mode.
incorporates a durable one piece plastic housing. The ProMite offers
Pro Sport Lt
3
can be left on indefinitely without harming
