PROGRAMMING YOUR ESC
1
Connect the battery
Enter Programming Mode
2
Press the
SET button
for 1s
Select the parameter you wish to modify
3
Press the SET button
1 time to select the
1st parameter...
LED blinks 1 time
4
Press the SET button
for 3s to modify
the setting of the
parameter
5
Use the SET button
to change the setting
of the parameter.
6
Press the SET button
for 3s to save the
new setting
8
Switch ON
Reset to factory default settings
OR
2
LED
blinks
3
Press 1 time
LED blinks
1 time
7
Switch OFF
ESC to complete
the procedure
Press the
SET button
for 5s
...press the SET button
2 times to select the
2nd parameter etc.
LED blinks 2 times
Press 2 times etc.
LED blinks
2 times
Copyright Team Orion © 2014
