System Requirements; Software-Installation; English - i-tec C31MYSAFENVME Bedienungsanleitung

i-tec MySafe USB-C M.2 NVMe SSD External Case
SPECIFICATION
• External USB-C case for M.2 M-Key NVMe SSD discs
• Transferrable interface: 1x USB-C 3.1, Gen. 2 (up
to 10Gbps)
• Compatible with M-Key NVMe discs with sizes
2230, 2242, 2260, 2280
• Plug & Play function
• Active LED diode indicating the case state (lights –
is connected, twinkles – record/reading is going on)
• Power supply 5V, 900mA
• Weight: 76 g
• Dimensions: 100 x 14 x 9 mm

SYSTEM REQUIREMENTS

Windows 7/8/8.1/10 32/64bit, Mac OS 10.x and higher –
automatic installation of drivers from the system. A free
USB-C port.
M.2 DISC HARDWARE INSTALLATION
Go on according to the following instructions:
1. Screw out 2 pcs of screws on the connector side of
the case and take off the cover.
2. Take out the motherboard.
3. Insert M.2 disc so that the slot in the disc
corresponds to the slot on the M.2 connector. After
that, screw up the M.2 disc on the opposite side to
the motherboard. Insert the motherboard together
with the M.2 disc back and screw up the pair of the
screws.
4. Connect a USB cable to the case. Now the device is
ready for using.
SOFTWARE INSTALLATION
Windows 7/8/8.1/10 32/64bit or Mac OS 10.x and higher
After connecting the device to a computer, detection
and automatic installation of drivers from the system
will be performed.
6 |

ENGLISH
