i-tec MySafe 2.5" External Case for M.2 SATA SSD

SPECIFICATION

• External 2,5" case for M.2 B-Key SATA Based SSD discs
• Transferrable interface: SATA
• Compatible with M.2 B-Key SATA Based SSD discs with sizes 2242, 2260, 2280
• It supports the Plug & Play function
• Power supply 3,3 V, max 2 A
• Weight: 44 g
• Dimensions: 100 x 70 x 7 mm

SYSTEM REQUIREMENTS

• Windows 7 / 8 / 8.1 / 10 32/64bit, Mac OS 10.x and higher – automatic
installation of drivers from the system
• Free 2,5" SATA slot.
M.2 DISC HARDWARE INSTALLATION
Go on according to the following instructions:
1. Fold up the case cover and unscrew 4 bolts holding the motherboard.
2. Take out the motherboard.
3. Insert M.2 disc so that the slot in the disc corresponds to the slot on the
M.2 connector. After that, screw up the M.2 disc on the opposite side to the
motherboard. Insert the motherboard together with the M.2 disc back and
screw up the pair of the screws.
4. Screw the motherboard back and latch the case cover.
5. Insert the case into a corresponding slot of your laptop according to the
laptop manual. In case of a desktop computer – into a free position, and
connect the SATA data connector and the SATA feeding connector.
6. Connect a USB cable to the case. Now the device is ready for using.
SOFTWARE INSTALLATION
Windows 7 / 8 / 8.1 / 10 32/64bit or Mac OS 10.x and higher
After connecting the device to a computer, detection and automatic
installation of drivers from the system will be performed.
Remark: The case surface can be warmed up during operation. It is a usual
operational feature and doesn't mean a defect. This warming-up is caused
by cooling the electronics inside the case. We recommend not covering the
case by things.
Remark: For correct function of the device, firstly it is necessary to format the
new disk Proceed according to the below mentioned instructions. As far as the
disk was earlier used, then this might not be a necessity. By formatting, you
will always lose your already saved data.
Remark: We recommend that you save essential or valuable data on more than
one disks or other recording media
4 | ENGLISH
FORMATTING A NEW HDD
1. Click with the right button on „Desktop".
2. Select „Administrate".
3. Click on „Disc administration".
4. Select HDD with the marking „Unassigned" or „Uninitialized" and with the
specified capacity of the inserted disc (usually a number lower by same digit
places is displayed).
5. Provided the disc is not initialized, click on the left field by the right button
and select „Initialize disc".
6. Click with the right button on the area of the disc and select „New simple
bunch", click on „Next".
7. Leave the maximum bunch size and click on „Next".
8. Select „Assign a letter of the unit" and click on „Next".
9. Select „Format the bunch with the following setting" (leave the initial
settings). Click on „Next" and „Finish".
10. HDD will be formatted. The duration of formatting depends on the HDD
size; afterwards the HDD will be viewable in the system.
PACKAGE CONTENT
• External 2,5" case for M.2 SATA disc
• User's Guide
FAQ
Question: The operation system hasn't detected the case.
Answer: Connect the device to other SATA connector.
Question: M.2 disc is not viewable in the system.
Answer: Please sure that M.2 has been formatted.
Question: The case cover is heated up during operation.
Answer: Heating up of the cover, mainly during intensive recording, is
a usual feature and doesn't mean a defect. The cover cools down the inside
electronics of the case and M.2 disc. We recommend ensuring an access for
air into the case and don't cover it unnecessarily by other things.
Question: You cannot insert the M.2 disk.
Reply: The case is only designed for the SSD based (NGFF) disks. It is not
possible to use PCIe based (NVMe) disks. They use different sockets and
technologies.
Quick Start
ENGLISH | 5
