TLMR 101 Batteriewechsel / Battery change / Remplacement de batterie / Cambio de la batería
Remove TLMR from holder
2
1 1
Change batteries
4 x New
4 x Old
+ + + + +
Insert TLMR into holder Fig. 13
Click
1
Fig. 10 Check seal for damages
+ + +
Order-No. 541-34901-2
Recycle used batteries
Fig. 8
15°
Fig. 11
Fig. 14

Li-ion Batteries

EWC-CODE: 16 06 05
