HDMI user guide

1. USB interface.
A: Connect a mouse to the USB port. Use the mouse to control the camera directly.
B: Connect the USB port to PC to make the camera work as a Driver-Free camera.
POWER LIGHT
USB
SD CARD
2. HDMI interface.
Use the HDMI cable to connect the camera to the HDMI monitor.
3. Power interface.
Please use the provided 12V2A power supply. When power is plugged in the red light is on. When switch on the
camera blue light is on.
4. ON/OFF KEY
Press and hold the ON/OFF key until the blue light is ON, press the ON/OFF key again to turn the camera off.
5. SD CARD
To get faster and more stable data transfer recommend to use "Class10" SD card we supply a 8 giga SD card.
6. C MOUNT
Standard C-mount optical port.
HDMI
Page 6
WORKING LIGHT
POWER
TURN ON/OFF
