Problem Solving - Summer Infant WideView 2.0 Bedienungsanleitung

29586 WideView 2.0 Monitor User Guide 10L Eng.pdf
The handheld unit and the camera are paired at the factory for privacy reasons. If the handheld and camera
are not paired with each other for any reason, follow steps to pair:
Step 1: Move the handheld unit to the same area as the camera.
Step 2: Power on the camera AND handheld.
Step 3: Press and hold the "ON/OFF/NIGHTLIGHT
blinks repeatedly. When the blue light begins blinking, your camera is in pairing mode.
Step 4: Press the "Menu/Enter" button on the handheld.
Step 5: Using the "Down" arrow, highlight "ADD CAM" and press the "Menu/Enter" button.
Step 6: Choose which of the 4 cameras you would like to pair.
Step 7: Press the "Menu/Enter" button again to begin pairing. A signal bar will appear once pairing begins.
Step 8: Once successfully paired, the blue light will stop blinking and video will appear on the monitor screen.
If this is unsuccessful, you should repeat steps above making sure the camera and monitor are close enough to
each other for pairing.
ADDI NG A DDI T I ONA L C AM ERAS/ REPL ACE MENT PARTS
Note: This product accepts up to 4 cameras and operates on audio and video auto-scan to view each camera
on an 8-second rotation. To order an additional camera, or if you need a replacement part, please contact our
Consumer Relations Team by phone at +44 (0) 1442 505000 (option 1), by email custserviceuk@summerinfant.com,
or via our website www.summerinfant.co.uk
Please note: the SCAN, DEL, ADD, VIEW CAM menu options are only used with additional cameras.
No picture or sound
• Make sure the camera and handheld monitor unit
are paired
• Make sure the camera and handheld monitor unit
are turned on
• Make sure the AC adapters are plugged in
• Make sure the outlets are working
Sound but no picture
• Press the Quick View/Video On-Off Button once to
turn on video mode
• Check to make sure nothing is blocking the camera
• Test reception by moving the handheld unit and/or
camera to different locations
• Make sure the camera and handheld monitor unit
are paired.
Picture but no sound
• Power the handheld completely off, then turn
handheld back on.
• Turn up the volume using Volume Control
2 29/12/2016
PA I RING MONIT OR & C AMERA
" button on the camera for 10 seconds until the blue light
PROB LE M SOL VING
Picture not clear
• Position the handheld unit closer to the camera
• Move the handheld unit away from other electronic
devices, cordless phones, etc.
• Adjust the brightness using the Brightness Control
• Test reception by moving the handheld unit and/or
camera to different locations
Squealing sound coming from speaker on Handheld Unit
• Move the handheld unit and camera further away
from each other
• Turn the volume down using Volume Control
• Power the handheld completely off, remove and
re-insert the battery then turn handheld back on.
09:00
