Connect
Inputs 1 and 2 Outputs 1 and 2
Power/Standby
Line (XLR) and Instrument (Jack)
Bright when unit is on,
dim when in standby
MIDI In Ethernet Outputs 1 – 8 Outputs 9 – 16
MIDI Thru Inputs 1 – 8 Inputs 9 – 16
DC Power
+5V, ±15Vdc from PSU
• Please refer to pages 37 and 39 for connector pinouts
