Installation Manual Sensor Box
2 Installation Manual Sensor Box
2.1

Technical Description

TM
The Solar-Log
monocrystalline solar-cell.
This very reliable and rugged sensor as well as the component
parts are designed for long-lasting outdoor use (IP65).
TM
The Solar-Log
PV-Plant with the measurements of the sensor. If the
TM
Solar-Log detects a definable difference an error message
will be generated.
Opening the sensor is not necessary and
would lead to a loss of guarantee.
2.2 Mechanical Installation Sensor Box
The Sensor Box must be mounted parallel; this means the
same adjustment and pitch as the solar-modules, fastened
with screws on the substructure. The sensor should be
mounted at a place where there are no shadows. A complex
mounting of a cell-temperature-sensor is not necessary, it is
included within the irradiance sensor.
Sensor Box is equipped with a high-quality
continuously compares the production of the
Solar-Log
TM
