6. Technical data

6.1.

Data sheet

Frequency range
EoC input/output
IP signal
TV output
Through loss
Output level min. 1...30 MHz
Output level min. 30...68 MHz
Network
Gross data rate
Net data rate
Range
Modulation
Encryption
Ethernet interface
Network standards
WiFi network standard
Frequency range
Connections (TV/EoC)
Connections (LAN)
LEDs
Switching power supply unit
Power consumption
Operating temperature
Dimensions
Corresponds to the standards
2015-06-30 | © AXING AG Schweiz | Konstrukions -, Typenänderung, Irrtümer und Druckfehler vorbehalten
2...1006 MHz
2...68 MHz
85...1006 MHz
<0,5 dB
100 dBμV
90 dBμV
Up to 64 EoC modems
500 Mbps
230 Mbps
up to 700 m
4096/1024/256/64/16/8-QAM, QPSK, BPSK and
ROBO modulation scheme
128 bit AES
10/100/1000 Mbps
Home Plug AV IEEE1901, IEEE802.3, IEEE802.3u
IEEE 802.11/b/g/n
13 channels 2.412GHz~2.472GHz
2 F sockets
2 RJ 45
Power /EoC /LAN/WiFi
110-230 V~ 50/60 Hz
max. 5.5 W
0°C ~ 40°C
145 (W) x 82.5 (D) x 33 (H) mm
EN 50083-2 Class A
13
