GB USA
Discription
① Backwards Indicator
② Forwards Indicator
③ Number of Sheets Display
④ Total Value Display
⑤ Euro Indicator
⑥ Britsh Pound
(or other banknote) Indicator
⑦ Currency Selection Key
⑧ Power On/Off Key
⑨ Exit Direction Key
⑩ Entrance
⑪ DC Input Socket
⑫ Exit
⑬ Cover
I. Specification
1. Test features:
2. Dimension:
3. AC Supply voltage:
4. DC supply voltage:
5. Operating temperature: 0°C – 45°C
6. Storage temperature: - 20°C – 65°C
7. Battery:
8. Power Consumption:
9. Speed:
II. Key Operation
1. Turn On/Off
By press Power On/Off Key and hold it for about 2
second, user can turn on the machine or vice versa.
When the machine is in sleeping mode (described in
part III. Operation Instruction), pressing Power
On/Off Key will make the machine wake up.
6
COMSAFE MOBILE CONTROL
Mobil-5.06 print

Front view

⑦
⑧
⑨
⑩
IR MG Length
221 x 132 x 85 mm
AC 100V—240V 50/60Hz
DC 12V/1A
Rechargeable Lithium
Battery 11.1V- 800mAH
< 10W
< 0.5 second/sheet
25.02.2009
⑫
2. Select Detected Currency
This Equipment is capable of detecting more than
one kind of currency, Press the Currency Selection
Key and hold it for about 2 seconds, the currency
being tested will switch over between Euro and
British Pound (or another type of banknote), and the
corresponding Currency Indicator (for example Euro
Indicator ) turns on. The default currency being
tested is Euro when power on.
12:55 Uhr Seite 6
①
②
③
④
⑤
⑥
⑬

Rear view

⑪
