G
USB
USB B type jack
Pin
Signal
1 +5V
2 - Data
3 + Data
4 Ground
H
HDMI
• Type :Digital audio/video connector
• Audio signal : Linear PCM (Sampling rate; 32/44.1/48 kHz)
Pin
Signal
1
T.M.D.S. Data2 +
2
T.M.D.S. Data2 Shield
3
T.M.D.S. Data2 -
4
T.M.D.S. Data1 +
5
T.M.D.S. Data1 Shield
6
T.M.D.S. Data1 -
7
T.M.D.S. Data0 +
COMPUTER IN1
COMPUTER IN2
S-VIDEO
K
VIDEO
4
3
2
1
Pin
8
T.M.D.S. Data0 Shield
9
T.M.D.S. Data0 -
10 T.M.D.S. Clock +
11 T.M.D.S. Clock Shield
12 T.M.D.S. Clock -
13 CEC
14 Reserved(N.C. on device)
Connection to the ports (continued)
H
G
HDMI
USB
Signal
Pin
15 SCL
16 SDA
17 DDC/CEC Ground
18 +5V Power
19 Hot Plug Detect
AUDIO OUT
AUDIO IN
18 16 14 12 10
8
6
4
2
19 17 15 13 11
9
7
5
3
Signal
1
5
