ZyWALL 70 Internet Security Appliance Quick Start Guide Version 4.0 8/2005 Table of Contents ENGLISH DEUTSCH ESPAÑOL FRANÇAIS ITALIANO 繁體中文 РУССКИЙ...
ENGLISH Overview The ZyWALL 70 is a load-balancing, dual WAN firewall with VPN, bandwidth management, content filtering, anti-spam, anti-virus, IDP (Intrusion Detection and Protection) and many other features. You can use it as a transparent firewall and not reconfigure your network nor configure the ZyWALL’s routing features. The ZyWALL increases network security by providing DMZ ports for use with publicly accessible servers.
Seite 4
ENGLISH Do the following to make hardware connections for initial setup. 1 Use an Ethernet cable to connect the LAN port to a computer. You can also use Ethernet cables to connect public servers (web, e-mail, FTP, etc.) to the DMZ ports. 2 Use another Ethernet cable(s) to connect the WAN 1 and/or WAN 2 port to an Ethernet jack with Internet access.
Seite 5
ENGLISH 2 Accessing the Web Configurator Use this section to configure the WAN 1 interface for Internet access. 1 Launch your web browser. Enter 192.168.1.1 (the 2 Click Login (the default password 1234 is already ZyWALL’s default IP address) as the address. entered).
ENGLISH 6 Check the Network Status table. If the WAN 1 status is not Down and there is an IP address, go to Section If the WAN 1 status is Down (or there is not an IP address), click Internet Access and Section 4 configure WAN 1.
Seite 7
ENGLISH 1 Click MAINTENANCE in the navigation panel and then Device Mode. 2 Select Bridge and configure a (static) IP address subnet mask and gateway IP address for the ZyWALL’s LAN, WAN, DMZ and WLAN interfaces. 3 Click Apply. The ZyWALL restarts.
Seite 8
ENGLISH • Ethernet Encapsulation Configure a Roadrunner service in the NETWORK WAN screens (use the WAN 1 tab). • PPP over Ethernet or PPTP Encapsulation Select Nailed-Up when you want your connection up all the time (this could be expensive if your ISP bills you for Internet usage time instead of a flat monthly fee).
Seite 9
ENGLISH 2 Click Next to display the screen where you can register your ZyWALL with myZyXEL.com (ZyXEL’s online services center) and activate the free content filtering, anti-spam, anti-virus and IDP trial applications. Otherwise, click Skip and then Close to complete Internet access setup.
Seite 10
ENGLISH 5 The following screen displays if the registration was not successful. Click Return to go back to the Device Registration screen and check your settings. 6 Click Close to leave the wizard screen when the registration and activation are done. Note: If you want to activate a standard service with your iCard’s PIN number (license key), use the...
Seite 11
ENGLISH 2 Specify an IP address and subnet mask for the DMZ interface. If you use private IP addresses on the DMZ, use NAT to make the servers publicly accessible (see Section A public IP address must be on a separate subnet from the WAN port’s public IP address.
Seite 12
ENGLISH 1 Click ADVANCED, NAT in the navigation panel and then Port Forwarding. 2 Select the Active check box. 3 Type a name for the rule. 4 Type the port number that the service uses. 5 Type the HTTP server’s IP address. 6 Click Apply.
Seite 13
ENGLISH 8 VPN Rule Setup A VPN (Virtual Private Network) tunnel gives you a secure connection to another computer or network. A gateway policy identifies the IPSec routers at either end of a VPN tunnel. A network policy specifies which devices (behind the IPSec routers) can use the VPN tunnel.
Seite 14
ENGLISH Note: Your settings are not saved when you click Back. 2 Use this screen to configure the gateway policy. 3 Use this screen to configure the network policy. Name: Enter a name to identify the gateway policy. Leave the Active check box selected. Remote Gateway Address: Enter the IP address or Name: Enter a name to identify the network policy.
Seite 15
ENGLISH Note: Make sure that the remote IPSec router uses the same security settings that you configure in the next two screens. Negotiation Mode: Select Main Mode for identity protection. Select Aggressive Mode to allow more incoming connections from dynamic IP addresses to use separate passwords. Note: Multiple SAs (security associations) connecting through a secure gateway must have the same negotiation mode.
Seite 16
ENGLISH 6 Check your VPN settings. Click Finish to save the 7 Click Close in the final screen to complete the settings. VPN wizard setup. Continue with the next section to activate the VPN rule and establish a VPN connection. 8.1 Using the VPN Connection Use VPN tunnels to securely send and retrieve files, and allow remote access to corporate networks, web servers and e-mail.
ENGLISH 9 Troubleshooting Problem Corrective Action None of the LEDs Make sure that you have the power cord connected to the ZyWALL and plugged in to an turn on. appropriate power source. Make sure you have the ZyWALL turned on. Check all cable connections.
Seite 18
Procedure to View a Product’s Certification(s) 1 Go to www.zyxel.com. 2 Select your product from the drop-down list box on the ZyXEL home page to go to that product's page. 3 Select the certification you wish to view from this page.
DEUTSCH Übersicht Die ZyWALL 70 ist eine Load-balancing-, Dual-WAN-Firewall mit VPN, Bandbreitenmanagement, Content Filtering, Anti-Spam, Anti-Virus, IDP (Intrusion Detection and Protection) und vielen anderen Funktionen. Sie können sie als transparente Firewall verwenden, ohne das Netzwerk neu zu konfigurieren und die Routingfunktionen des Geräts zu konfigurieren.
Seite 20
DEUTSCH Wenn Sie das Gerät installieren, müssen Sie die Hardwaregeräte folgendermaßen anschließen. 1 Verbinden Sie den LAN-Port mit einem Ethernet-Kabel mit dem Computer. Mit Ethernet-Kabeln können Sie auch öffentliche Server (Internet, E-Mail, FTP, usw.) an die DMZ-Ports anschließen. 2 Schließen Sie mit einem anderen Ethernet-Kabel den WAN 1- und/oder WAN 2-Port an die Ethernet- Buchse mit Internetzugriff an.
DEUTSCH 2 Zugriff auf den Web-Konfigurator In diesem Abschnitt wird beschrieben, wie die WAN 1-Schnittstelle für den Internetzugriff konfiguriert wird. 1 Starten Sie Ihren Internetbrowser. Geben Sie als 2 Klicken Sie auf Login (Einloggen) (das Adresse 192.168.1.1 (die IP-Standardadresse Standardpasswort 1234 ist bereits vorgegeben). des ZyWALL) ein.
Seite 22
DEUTSCH 6 Prüfen Sie die Netzwerkstatus tabelle. Wenn der Status von WAN 1 nicht Down ist und eine IP-Adresse angegeben ist, gehen Sie zu Abschnitt Wenn der Status von WAN 1 Down ist (oder keine IP- Adresse angegeben ist), klicken Sie auf Internet Access (Internetzugriff) und konfigurieren Sie mit...
DEUTSCH 1 Klicken Sie in der Navigationsleiste auf MAINTENANCE (Wartung) und dann auf Device Mode (Gerätemodus). 2 Wählen Sie Bridge (Brücke) und konfigurieren Sie eine statische) IP- Adressen-Subnetmaske und eine Gateway-IP- Adresse für die LAN-, WAN-, DMZ- und WLAN- Schnittstelle der ZyWALL. 3 Klicken Sie auf Apply (Übernehmen).
Seite 24
DEUTSCH • Ethernet Encapsulation Konfigurieren Sie einen Roadrunnerdienst in den NETWORK WAN (Netzwerk-WAN) Fenstern (auf der Registerkarte WAN 1). • PPP over Ethernet or PPTP Encapsulation Wählen Sie Nailed-Up, wenn die Verbindung dauerhaft aufrecht erhalten werden soll (das kann jedoch sehr teuer sein, wenn Ihr Internetdienstanbieter Ihnen die Benutzungsdauer anstelle eines monatlichen Pauschalbetrags in Rechnung stellt).
Seite 25
2 Klicken Sie auf Next (Weiter), um das Fenster aufzurufen, in dem Sie Ihre ZyWALL bei myZyXEL.com (Online-Servicezentrum von ZyXEL) registrieren und den kostenlosen Inhaltsfilter sowie die Anti-Spam-, Antiviren- und IDP-Testsoftware aktivieren können. Oder Sie klicken auf Skip (Überspringen) und...
Seite 26
DEUTSCH 5 Im folgenden Fenster wird angezeigt, wenn die Registrierung nicht erfolgreich durchgeführt wurde. Klicken Sie auf Return (Zuruck), um zum Fenster Device Registration (Gerät registrieren) zurückzukehren. Prüfen Sie noch einmal Ihre Einstellungen. 6 Klicken Sie auf Close (Schliessen), um nach der Registrierung und Aktivierung den Assistenten zu verlassen.
Seite 27
DEUTSCH 2 Geben Sie für die DMZ-Schnittstelle eine IP- Adresse und eine Subnetmaske an. Wenn Sie in der DMZ private IP-Adressen verwenden, können Sie die Server mit NAT öffentlich zugänglich machen (siehe Abschnitt Eine öffentliche IP-Adresse muss sich auf einem anderen Subnetz als dem der öffentlichen IP-Adresse eines WAN-Ports befinden.
Seite 28
DEUTSCH 1 Klicken Sie in der Navigationsleiste auf ADVANCED (ERWEITERT), NAT und dann auf Port Forwarding (Portweiterleitung). 2 Wählen Sie das Kontrollfeld Active (Aktiv). 3 Geben Sie eine Bezeichnung für die Regel ein. 4 Geben Sie die Portnummer ein, die der Dienst verwendet.
DEUTSCH 8 Einstellen der VPN-Regeln Mit einem VPN-Tunnel (Virtual Private Network) haben Sie eine sichere Verbindung zu anderen Computern oder Netzwerken. Eine Gateway-Policy identifiziert an jedem Ende eines VPN-Tunnels die IPSec- Router. In einer Netzwerk-Policy ist festgelegt, welche Geräte (hinter den IPSec-Routern) den VPN-Tunnel benutzen dürfen.
Seite 30
DEUTSCH Hinweis: Wenn Sie auf Back (Zurück) klicken, werden Ihre Einstellungen nicht gespeichert. 2 In diesem Fenster können Sie die Gateway-Policy 3 In diesem Fenster können Sie die Netzwerk-Policy konfigurieren. konfigurieren. Name : Geben Sie einen Namen ein, um die Lassen Sie die Markierung im Kontrollfeld Active Gateway-Policy zu bezeichnen.
Seite 31
DEUTSCH Hinweis: Stellen Sie sicher, dass der Remote-IPSec-Router dieselben Sicherheitseinstellungen verwendet, die Sie in den zwei folgenden Fenstern festlegen. Negotiation Mode (Negotiation-Modus): Wählen Sie Main Mode (Hauptmodus) für den Identitätsschutz. Wählen Sie Aggressive Mode (Agressiver Modus), wenn mehrere eingehende Verbindungen von dynamischen IP-Adressen verschiedene Passwörter benutzen sollen.
Seite 32
DEUTSCH 6 Prüfen Sie Ihre VPN-Einstellungen. Klicken Sie 7 Klicken Sie beim letzten Fenster auf Close auf Finish (Fertig stellen), um die Einstellungen (Schließen), um die Installation mit dem VPN- zu speichern. Assistenten zu beenden. Fahren Sie mit dem nächsten Abschnitt fort, um die VPN-Regel zu aktivieren und eine VPN-Verbindung herzustellen.
DEUTSCH 9 Problembeseitigung Problem Lösungsmöglichkeit Es leuchtet keine Stellen Sie sicher, dass das Netzkabel richtig an die ZyWALL und an eine Netzsteckdose der LED- angeschlossen wurde. Stellen Sie sicher, dass die ZyWALL eingeschaltet wurde. Überprüfen Anzeigen. Sie alle Kabelverbindungen. Wenn die LEDs auch dann nicht leuchten, besteht möglicherweise ein Hardwareproblem. In diesem Fall sollten Sie sich an Ihren Händler wenden.
8 Schließen Sie das Fenster Netzwerkverbindungen. Schritte zum Ansehen der Produktzertifizierung(en) 1 Besuchen Sie www.zyxel.com. 2 Wählen Sie auf der ZyXEL-Homepage aus der Liste der Produkte Ihr Produkt aus. 3 Wählen Sie auf dieser die Zertifizierung aus, die Sie gerne angezeigt haben möchten.
ESPAÑOL Vista previa El ZyWALL 70 es un cortafuegos de WAN dual, con balanceo de carga, soporte de VPNs, gestión del ancho de banda, filtrado de contenidos, anti-spam, antivirus, IDP (Intrusion Detection and Protection) y muchas otras características. Puede usarlo como cortafuegos transparente sin reconfigurar su red ni configurar las características de enrutamiento de ZyWALL.
Seite 36
ESPAÑOL Realice lo siguiente para crear conexiones de hardware para la configuración inicial. 1 Use un cable Ethernet para conectar el puerto LAN a un ordenador. También puede usar cables Ethernet para conectar servidores públicos (web, correo electrónico, FTP, etc.) a los puertos DMZ. 2 Use otro(s) cable(s) Ethernet para conectar el puerto WAN 1 y/o WAN 2 a un dispositivo Ethernet con acceso a Internet.
Seite 37
ESPAÑOL 2 Acceso al configurador Web Use esta sección para configurar la interfaz WAN 1 para el acceso a Internet. 1 Abra su explorador de web. Introduzca 2 Haga clic en Login (acceso) (la contraseña 192.168.1.1 (la dirección IP predeterminada del predeterminada 1234 ya está...
Seite 38
ESPAÑOL 6 Compruebe la tabla Network Status (estado de la red). Si el estado de WAN 1 no es Down (Caído) y hay una dirección IP, vaya a Sección Si el estado de la WAN 1 es Down (Caído) (o no hay una dirección IP), haga clic en Internet Access (acceso a Internet) y...
ESPAÑOL 1 Haga clic en MAINTENANCE (Mantenimiento) en el panel de navegación y luego en Device Mode (Modo de Dispositivo). 2 Seleccione Bridge (Puente) y configure una máscara de subred de dirección IP (estática) y una dirección IP de puerta de enlace para las interfaces LAN, WAN, DMZ y WLAN del...
Seite 40
ESPAÑOL • Encapsulación Ethernet Configure un servicio Correcaminos en las pantallas WAN de NETWORK (Red) (use la ficha WAN 1). • Encapsulación PPP sobre Ethernet o PPTP Seleccione Nailed-Up (Forzada) cuando desee que su conexión esté arriba todo el tiempo (esto puede resultar caro si su ISP le cobra por el tiempo de uso de Internet en lugar de una cuota fija mensual).
Seite 41
2 Haga clic en Next (Siguiente) para mostrar la pantalla donde podra registrar ZyWALL con myZyXEL.com (centro de servicios en linea de ZyXEL) y activar el filtrado de contenidos, anti-spam, antivirus y aplicaciones de prueba IDP. En caso contrario, haga clic en Skip...
Seite 42
ESPAÑOL 5 La pantalla siguiente muestra si el registro no ha tenido exito. Haga clic en Return (Volver) para regresar a la pantalla Device Registration (Registro del dispositivo) y comprobar su configuracion. 6 Haga clic en Close (Cerrar) para salir de la pantalla del asistente cuando se hayan realizado el registro y la activacion.
Seite 43
ESPAÑOL 2 Especifique una dirección IP y máscara de subred para la interfaz DMZ. Si usa direcciones IP privadas en la DMZ, use NAT para hacer a los servidores accesibles públicamente (ver Sección Una dirección IP pública debe estar en una subred separada de las direcciones IP públicas de los puertos WAN.
Seite 44
ESPAÑOL 1 Haga clic en ADVANCED (AVANZADA), NAT en el panel de navegación y luego en Port Forwarding (Reenvío de puerto). 2 Seleccione la casilla de verificación Active (Activa). 3 Escriba un nombre para la regla. 4 Escriba el número que el servicio usa.
Seite 45
ESPAÑOL 8 Configuración de reglas VPN Un túnel VPN (Virtual Private Network - Red Privada Virtual) le ofrece una conexión segura a otro ordenador o red. Una política de puerta de enlace identifica a los enrutadores IPSec en ambos extremos del túnel VPN. Una política de red especifica qué...
Seite 46
ESPAÑOL Nota: Su configuración no se grabará cuando haga clic en Back (Atrás). 2 Use esta pantalla para configurar la política de la 3 Use esta pantalla para configurar la política de la puerta de enlace. red. Name (Nombre): Introduzca un nombre para Deje la casilla de verificación Active (Activa) identificar la política de la puerta de enlace.
Seite 47
ESPAÑOL Nota: Compruebe que el enrutador IPSec usa la misma configuración de seguridad que la que configurará en las siguientes dos pantallas. Negotiation Mode (Modo de negociación): Seleccione Main Mode (Modo principal) para la protección de la identidad. Seleccione Aggressive Mode (Modo agresivo) para permitir que más conexiones entrantes desde direcciones IP dinámicas usen contraseñas separadas.
Seite 48
ESPAÑOL 6 Compruebe su configuración VPN. Haga clic en 7 Haga clic en Close (Cerrar) en la pantalla final Finish (Finalizar) para guardar la configuración. para completar la configuración del asistente para VPN. Continúe con la siguiente sección para activar la regla VPN y establecer una conexión VPN.
ESPAÑOL 9 Solución de problemas Problema Solución Ninguno de los Asegúrese de haber conectado el cable de alimentación al ZyWALL y si lo ha enchufado en LEDs se una fuente de alimentación apropiada. Compruebe que el ZyWALL está encendido. enciende. Compruebe todas las conexiones de los cables.
Seite 50
Procedimiento para ver la(s) certificación(es) del producto 1 Vaya a www.zyxel.com. 2 Seleccione su producto de la lista desplegable en la página inicial de ZyXEL para ir a la página de ese producto. 3 Seleccione la certificación que desee visualizar en esta página.
Seite 51
FRANÇAIS Présentation Le ZyWALL 70 est un pare-feu double WAN à équilibrage de charge avec VPN, gestion de bande passante, filtrage de contenu, antispam, antivirus, détection et protection contre les intrusions (IDP) et de nombreuses autres fonctionnalités. Vous pouvez l'utiliser comme un pare-feu transparent et ne pas reconfigurer votre réseau ni configurer les fonctionnalités de routage du ZyWALL.
Seite 52
FRANÇAIS Procédez comme suit pour effectuer les connexions matérielles pour l'installation initiale. 1 Utilisez un câble Ethernet pour connecter le port LAN à un ordinateur. Vous pouvez aussi utiliser les câbles Ethernet pour connecter les serveurs publics (web, e-mail, FTP, etc.) aux ports DMZ. 2 Utilisez un autre (ou d'autres) câble(s) Ethernet pour connecter le port WAN 1 et/ou WAN 2 à...
Seite 53
FRANÇAIS 2 Accéder au Configurateur Web Utilisez cette section pour configurer l'interface WAN 1 pour l'accès à Internet. 1 Lancez votre navigateur web. Entrez 192.168.1.1 2 Cliquez sur Login (Ouverture de session) (le (l'adresse IP par défaut du ZyWALL) comme mot de passe par défaut 1234 est déjà...
Seite 54
FRANÇAIS 6 Reportez-vous au tableau d'Network Status (Etat du Réseau). Si l'état WAN 1 n'est pas Désactivé et qu'il y a une adresse IP, allez à la Section Si l'état WAN 1 est Désactivé (ou s'il n'y a pas d'adresse IP), cliquez sur Accès Internet et passez à...
Seite 55
FRANÇAIS 1 Cliquez sur MAINTENANCE dans le panneau de navigation et ensuite sur le Mode Périphérique. 2 Sélectionnez Pont et configurez une d'adresse IP (statique) de masque de sous-réseau et une adresse IP de passerelle pour les interfaces LAN, WAN, DMZ et WLAN du ZyWALL.
Seite 56
FRANÇAIS • Encapsulation Ethernet Configurer un service Roadrunner dans les écrans du NETWORK WAN (utilisez l'onglet WAN 1). • PPP over Ethernet ou PPTP Encapsulation Sélectionnez Nailed-Up quand vous voulez que votre connexion soit toujours active (cela peut être cher si votre ISP vous facture pour votre temps d'utilisation à...
Seite 57
FRANÇAIS 2 Cliquez sur Next (Suivant) pour afficher l'écran où vous pourrez inscrire votre ZyXEL sur MyZyXEL.com (Centre de services en ligne de ZyXEL) et activer les applications d'évaluation gratuites de filtrage de contenu, antispam, antivirus et IDP. Vous pouvez aussi cliquer sur Skip (Passer) et ensuite sur Close (Fermer) pour terminer l'installation de l'accès...
Seite 58
FRANÇAIS 5 Les écrans suivants s'affichent si l'enregistrement a échoué. Cliquez sur Return (Retour) pour retourner à l'écran Device Registration (Inscription matériel) et vérifier vos paramètres. 6 Cliquez sur Close (Fermer) pour quitter l'assistant quand l'inscription et l'action sont effectuées. Remarque: Si vous voulez activer un service standard avec le numéro PIN de votre iCard (clé...
Seite 59
FRANÇAIS 2 Spécifiez une adresse IP et un masque de sous- réseau pour l'interface DMZ. Si vous utilisez des adresses IP privées sur le DMZ, utilisez NAT pour rendre les serveurs accessibles au public (voir la Section Une adresse IP publique doit se trouver sur un sous-réseau séparé...
Seite 60
FRANÇAIS 1 Cliquez sur ADVANCED (AVANCÉ), NAT dans le panneau de navigation et ensuite sur Réacheminement de Port. 2 Sélectionnez la case à cocher Active. 3 Tapez un nom pour la règle. 4 Tapez le numéro de port que le service utilise.
Seite 61
FRANÇAIS 8 Installation de la règle VPN Un tunnel VPN (Virtual Private Network) vous offre une connexion sécurisée à un autre ordinateur ou réseau. Une stratégie de passerelle identifie les routeurs IPSec aux extrémités d'un tunnel VPN. Une stratégie de réseau spécifie les périphériques (derrière les routeurs IPSec) pouvant utiliser le tunnel VPN.
Seite 62
FRANÇAIS Remarque: Vos paramètres ne sont pas enregistrés quand vous cliquez sur Retour. 2 Utilisez cet écran pour configurer la stratégie de 3 Utilisez cet écran pour configurer la stratégie de passerelle. réseau. Nom : Entrez un nom pour identifier la stratégie de Laissez la case à...
Seite 63
FRANÇAIS Remarque: Vérifiez que le routeur IPSec distant utilise les mêmes paramètres de sécurité que ceux que vous configurez dans les deux écrans suivants. Mode de négociation : Sélectionnez Mode Principal pour la protection d'identité. Sélectionnez le Mode Agressif pour permettre à plus de connexions entrantes à partir des adresses IP dynamiques d'utiliser des mots de passe séparés.
Seite 64
FRANÇAIS 6 Vérifiez vos paramètres VPN. Cliquer sur 7 Cliquez sur Fermer dans l'écran final pour Terminer pour enregistrer les paramètres. terminer l'installation de l'assistant de VPN. Suivez la section suivante pour activer la règle VPN et établir une connexion VPN. 8.1 lUtiliser la Connexion VPN Utilisez les tunnels VPN pour envoyer et recevoir de manière sécurisée, et permettre l'accès à...
FRANÇAIS 9 Dépannage problème ACTION CORRECTIVE Aucune LED ne Vérifiez que votre cordon d'alimentation est connecté au ZyWALL et branché dans une prise s'allume. de courant appropriée. Vérifiez que le ZyWALL est allumé. Vérifiez toutes les connexions câblées. Si les LED ne s'allument toujours pas, cela signifie que vous avez peut-être un problème matériel.
Seite 66
Procédure pour Afficher la (les) certification(s) d'un produit 1 Allez à www.zyxel.com. 2 Sélectionnez votre produit dans la boîte de la liste déroulante dans la page d'accueil de ZyXEL pour aller à la page de ce produit. 3 Sélectionnez la certification que vous désirez consulter dans cette page.
ITALIANO Cenni generali ZyWALL 70 è un firewall con funzionalità di Load Balancing, a doppia WAN, dotato di funzioni di VPN, gestione della larghezza di banda, filtraggio dei contenuti, antispam, antivirus, IDP (Intrusion Detection and Protection) e molto altro. È possibile utilizzarlo come firewall trasparente ed evitare di riconfigurare la propria rete e di configurare le funzionalità...
Seite 68
ITALIANO Di seguito sono illustrati i collegamenti hardware per l'installazione iniziale. 1 Utilizzare un cavo Ethernet per collegare la porta LAN a un computer. È possibile utilizzare cavi Ethernet anche per collegare server pubblici (Web, E-mail, FTP, ecc.) alle porte DMZ. 2 Utilizzare altri cavi Ethernet per collegare la porta WAN 1 e/o WAN 2 a un jack Ethernet con accesso a Internet.
Seite 69
ITALIANO 2 Accesso allo strumento di configurazione Web Questa sezione spiega come configurare l'interfaccia WAN 1 per l'accesso a Internet. 1 Avviare il browser. Immettere 192.168.1.1 2 Fare clic su Login (accedi)(la password (l'indirizzo IP predefinito dello ZyWALL) nella predefinita 1234 è già immessa). barra dell'indirizzo.
ITALIANO 6 Controllare la tabella Network Status (stato della rete). Se lo stato della WAN 1 è not Down (non disattivata) ed è presente un indirizzo IP, passare a Sezione Se lo stato della WAN 1 è Down (disattivata) (oppure se non è presente un indirizzo IP), fare clic su Internet Access...
ITALIANO 1 Fare clic su MAINTENANCE (manutenzione) nel pannello di navigazione, quindi su Device Mode (modalità dispositivo). 2 Selezionare Bridge e immettere un indirizzo IP (statico), una subnet mask e un indirizzo IP del gateway per le interfacce LAN, WAN, DMZ e WLAN dello ZyWALL.
Seite 72
ITALIANO • Incapsulamento Ethernet Configurare un servizio Roadrunner nelle schermate NETWORK WAN (WAN di rete) (utilizzare la scheda WAN 1). • PPP over Ethernet oppure incapsulamento PPTP Selezionare Nailed-Up (riconnessione) quando si desidera che la connessione sia sempre attiva (questa opzione potrebbe rivelarsi costosa se il proprio ISP applica una tariffazione a tempo dell'accesso a Internet piuttosto che un costo mensile fisso).
Seite 73
2 Fare clic su Next (avanti) per visualizzare la schermata in cui e possibile registrare lo ZyWALL sul sito myZyXEL.com (centro di assistenza online ZyXEL) e attivare i servizi filtraggio dei contenuti, antispam, antivirus e IDP gratuiti in versione di valutazione.
Seite 74
ITALIANO 5 La seguente schermata indica se la registrazione non ha avuto esito positivo. Fare clic su Return (torna) per tornare alla schermata Device Registration (registrazione dispositivo) e controllare le impostazioni. 6 Fare clic su Close (chiudi) per chiudere la procedura guidata una volta terminata la registrazione e l'attivazione.
Seite 75
ITALIANO 2 Specificare un indirizzo IP e una subnet mask per l'interfaccia DMZ. Se si utilizzano indirizzi IP privati sulla DMZ, utilizzare la funzione NAT per rendere i server accessibili pubblicamente (vedere Sezione Un indirizzo IP pubblico deve trovarsi su una subnet separata rispetto all'indirizzo IP pubblico della porta WAN.
Seite 76
ITALIANO 1 Fare clic su ADVANCED (AVANZATO), NAT nel pannello di navigazione, quindi su Port Forwarding (inoltro delle porte). 2 Selezionare la casella di controllo Active (attiva). 3 Digitare un nome per la regola. 4 Digitare il numero di porta utilizzata dal servizio.
Seite 77
ITALIANO 8 Configurazione delle regole di VPN Un tunnel VPN (Virtual Private Network, rete privata virtuale) offre una connessione sicura a un altro computer o rete. Un criterio di gateway identifica i router IPSec a entrambe le estremità di un tunnel VPN. Un criterio di rete specifica quali dispositivi (dietro i router IPSec) possono utilizzare il...
Seite 78
ITALIANO Nota: Le impostazioni non vengono salvate quando si fa clic su Back (Indietro). 2 Utilizzare questa schermata per configurare il 3 Utilizzare questa schermata per configurare il criterio di gateway. criterio di rete. Name (nome): immettere un nome per identificare il Lasciare la casella di controllo Active (attiva) criterio di gateway.
Seite 79
ITALIANO Nota: Assicurarsi che il router IPSec remoto utilizzi le stesse impostazioni di sicurezza configurate nelle prossime due schermate. Negotiation Mode (modalità di negoziazione): selezionare Main Mode (modalità principale) come protezione dell'identità. Selezionare Aggressive Mode (modalità aggressiva) per consentire a più connessioni in ingresso provenienti da indirizzi IP dinamici di utilizzare password separate.
Seite 80
ITALIANO 6 Verificare le impostazioni della VPN. Fare clic su 7 Fare clic su Close (chiudi) nella schermata finale Finish (fine) per salvare le impostazioni. per completare l'installazione guidata della VPN. Continuare con la prossima sezione per attivare la regola VPN e stabilire una connessione VPN. 8.1 Uso della connessione VPN Utilizzare i tunnel VPN per inviare e ricevere in maniera sicura file e per consentire un accesso remoto alle reti aziendali, server Web ed e-mail.
ITALIANO 9 Risoluzione dei problemi Problema Azione correttiva Nessuno dei LED Assicurarsi di aver collegato il cavo di alimentazione allo ZyWALL e a una sorgente di è acceso. alimentazione appropriata. Assicurarsi che lo ZyWALL sia acceso. Controllare tutti i collegamenti dei cavi. Se i LED continuano a non accendersi, potrebbe esserci un guasto hardware.
Seite 82
Procedura per visualizzare le certificazioni di un prodotto 1 Aprire la pagina www.zyxel.com. 2 Selezionare il prodotto dall'elenco di riepilogo a discesa nella Home Page di ZyXEL per passare alla pagina del prodotto in questione. 3 Selezionare da questa pagina la certificazione che si desidera visualizzare.
Seite 99
РУССКИЙ Обзор Устройство ZyWALL 70 представляет собой межсетевой экран для глобальной сети с выравниванием нагрузки и имеет целый ряд функциональных возможностей, таких как виртуальные частные сети, управление пропускной способностью, фильтрация контента, защита от спама, защита от вирусов, IDP (Intrusion Detection and Protection - Обнаружение и защита от вторжения) и другие. Устройство можно...
РУССКИЙ 1 Подключение оборудования Вам потребуется следующее оборудование. ZyWALL Компьютер Кабели Ethernet Кабель питания Для подключения оборудования выполните следующие действия. 1 Для подключения порта LAN к компьютеру используйте кабель Ethernet. Вы также можете использовать кабели Ethernet для подключения общедоступных серверов (web, E-Mail, FTP и т. д.) к портам...
Seite 101
РУССКИЙ 3 Установите карту расширения ZyWALL Turbo, чтобы использовать функции защиты от вирусов и IDP, или установите беспроводной адаптер для подключения к беспроводной сети. Дополнительную информацию по карте расширения см. в руководстве по ZyWALL Turbo. Информацию по установке беспроводной сетевой карты см. в Техническом руководстве. 4 Для...
Seite 102
РУССКИЙ По умолчанию в ZyWALL установлен режим маршрутизатора. Если вы хотите использовать функции маршрутизации, такие как NAT, DHCP и VPN, переходите к следующему шагу. Если ZyWALL будет использоваться в качестве прозрачного межсетевого экрана, переходите к Раздел 6 Проверьте таблицу Network Status (Статус...
Seite 103
РУССКИЙ 1 В Панели навигации щелкните MAINTENANCE (ОБСЛУЖИВАНИЕ) и затем Device Mode (Режим устройства). 2 Выберите Bridge (Мост) и установите статический IP-адрес, маску подсети и IP-адрес шлюза для интерфейсов LAN, WAN, DMZ и WLAN. 3 Щелкните Apply (Применить). ZyWALL перезагрузится. Если...
Seite 104
РУССКИЙ • Инкапсуляция Ethernet Настройте службу Roadrunner с помощью окон WAN в разделе NETWORK (СЕТЬ) (закладка WAN 1). • PPP поверх Ethernet или инкапсуляция PPTP Выберите Nailed-Up (Постоянное), если вы хотите иметь постоянное соединение (такое соединение может быть достаточно дорогим, если Интернет-провайдер берет плату за время использования Интернет, а...
Seite 105
РУССКИЙ 2 Щелкните Next (Далее) для отображения окна, которое используется для регистрации ZyWALL на сайте myZyXEL.com (центр обслуживания ZyXEL) и активирования фильтрации контента, защиты от спама, защиты от вирусов и испытательных версии приложений IDP. В другом случае, щелкните Skip (Пропустить) и...
Seite 106
РУССКИЙ 5 Если регистрация не выполнена, появляется следующее окно. Щелкните Return (Вернуться) для возврата к окну Device Registration (Регистрация устройства) и проверьте настройки. 6 Щелкните Close (Закрыть), чтобы закрыть окно Мастера после выполнения регистрации и активирования служб. ПРИМЕЧАНИЕ: Для активации стандартной службы...
Seite 107
РУССКИЙ 1 В Панели навигации щелкните NETWORK (СЕТЬ), затем DMZ. 2 Введите IP-адрес и маску подсети для интерфейса DMZ. Если используется частный IP-адрес для DMZ, то чтобы сделать серверы доступными для всех пользователей, необходимо использовать NAT (см. Раздел Общедоступный IP-адрес должен находиться в подсети, отличной...
Seite 108
РУССКИЙ В следующем примере разрешается доступ из глобальной сети к серверу HTTP (web-сервер) в DMZ. Этот сервер имеет частный IP-адрес 10.0.0.20. 1 В Панели навигации щелкните ADVANCED (ДОПОЛНИТЕЛЬНО), затем NAT и затем Port Forwarding (Переадресация портов). 2 Установите флажок Active (Включить).
Seite 109
РУССКИЙ 8 Настройка правил виртуальной частной сети (VPN) Туннель VPN (Virtual Private Network - виртуальная частная сеть) обеспечивает защищенное соединение к другому компьютеру или сети. Стратегия шлюза определяет маршрутизаторы IPSec на каждом конце туннеля VPN. Сетевая политика определяет устройства (за маршрутизаторами...
Seite 110
РУССКИЙ ПРИМЕЧАНИЕ: Если щелкнуть Back (Назад), настройки не сохраняются. 2 Это окно используется для настройки 3 Это окно используется для настройки политики стратегии шлюза. сети. Name (Имя): Введите имя для идентификации Флажок Active (Включить) должен быть стратегии шлюза. установлен. Remote Gateway Address (Адрес удаленного Name (Имя): Введите...
Seite 111
РУССКИЙ ПРИМЕЧАНИЕ: Убедитесь, что удаленный маршрутизатор IPSec использует те же настройки безопасности, что будут настроены в следующих двух окнах. Режим согласования: Выберите Main Mode (Основной режим) для защиты конфиденциальности. Выберите Aggressive Mode (Рискованный режим), чтобы разрешить множество входящих подключений с динамическими IP-адресами и различными паролями. ПРИМЕЧАНИЕ: Несколько...
Seite 112
РУССКИЙ 4 Это окно используется для настройки 5 Это окно используется для настройки параметров туннеля IKE (Internet Key Exchange параметров IPSec. - протокол обмена ключами). 6 Проверьте настройки VPN. Щелкните Finish 7 В последнем окне щелкните Close (Закрыть) (Готово) для сохранения настроек. для...
РУССКИЙ 8.1 Использование соединения VPN Туннели VPN используются для защищенной отправки и поиска файлов, а также разрешения удаленного доступа к корпоративным сетям, web-серверам и почтовым серверам. Эти службы будут работать так, как если бы вы находились в офисе, а не подключались через Интернет. Например, правило...
Seite 114
РУССКИЙ Неисправность Способы устранения Отсутствует Проверьте кабельное соединение между ZyWALL и компьютером или концентратором. доступ к ZyWALL Подробнее см. Раздел из локальной Протестируйте соединение ZyWALL с сетевым компьютером с помощью команды сети. "ping". Убедитесь, что в компьютере установлена карта Ethernet и она работает нормально.
Seite 115
сети). 8 Закройте окно Network Connections (Сетевые подключения). Порядок просмотра сертификата(ов) на изделие 1 Перейдите на сайт www.zyxel.ru. 2 Выберите изделие из раскрывающегося списка на домашней странице ZyXEL для перехода на страницу, посвященную этому изделию. 3 Выберите сертификат для просмотра.
