Gangway • Steg • Opløbsbro - ledon CASTLE Montageprinzipien

17
Installation principles • Montageprinzipien • Montageprincipper
13 Gangway • Steg • Opløbsbro
1 2
M6x40 WD
Ø4,5X30 mm
3 4
BS-B
M8x25 CS
5 6
M8x25 CS
BS-S
BS-S
M8x45 CS
M8x45 CS
7 8
M8x30 CS
M8x30 CS
