Scaling Adjustments
In this section the picture of the main picture channel can be set.

Scaling Mode

Picture Flip

Zoom

Horizontal Pan

The for the main picture channel is
Scaling Mode
set here. As default, the main picture channel is
set to Expand . There are three more possible set-
tings for the main picture channel. The picture
can be set to Strech , Aspect
In this section the picture of the main picture
channel can be mirrored horizontally or verti-
cally.
In this section the Zoom
main picture channel is set. The value can be set
between 0 and 302. The default value is 0 (no
zoom).
In this section the Horizontal Pan
display detail) is set. The value entered here
depends on the selected zoom level. The default
horizontal pan is 0. When
position of the picture cannot be changed here.
Main menu
or 1.1 .
for the picture of the
(position of the
Zoom is set to 0, the
RackConsole 17HR · 15
