AXIS T91A Series Installation Guide
AXIS T91A Mounting Accessories
This installation guide provides instructions for installing the wall/parapet/ceiling/corner/pole
mounting accessories for Axis network cameras. For all other aspects of using the Axis network
camera, please see the Installation Guide and User's Manual, available from www.axis.com

Installation steps

1. Check the package contents against the list below
2. Hardware overview. See page 4
3. Install the hardware:
• Install the AXIS T91A61 Wall Mount, see page 6
• Install the AXIS T91A62 Parapet Mount, see page 7
• Install the AXIS T91A63 Ceiling Mount, see page 9
• Install the AXIS T91A64 Corner Mount, see page 11
• Install the AXIS T91A67 Pole Mount, see page 12

Package contents

Model
AXIS T91A61 Wall Mount
AXIS T91A62 Parapet Mount
AXIS T91A63 Ceiling Mount
AXIS T91A64 Corner Mount
AXIS T91A67 Pole Mount
Item
Wall bracket
Bracket holder
Parapet bracket
Bracket holder
Ceiling bracket
Bracket holder
Corner bracket (AXIS T91A61 required)
4 M8x22 screws
Pole bracket
Steel straps (steel strap tool not supplied)
Important!
This product must be used in
compliance with local laws and
regulations.
Page 3
