Device overview

7
• CPU: Octa-Core ARM Cortex-A53, 64 bit
• OS: Android 5.1 Lollipop
• Memory: 1GB DDR3 / 8GB Flash
• Outputs: HDMI 2.0/ CVBS
• Network: Wi-Fi 802.11 b/g/n, Ethernet (RJ-45)
The manufacturer reserves the right to change these speci cations & options without notice.
Initial Set Up
1. Unplug the power adapter.
2. Connect the HDMI cable to the HDMI output.
3. Connect the other end of the HDMI cable to
HDMI input on your TV/Monitor/Projector.
Note: HDMI cable not included.
4. Plug in the power adapter.
5. Remove Battery compartment cover from Remote Control and insert supplied batteries.
6. Select the HDMI input via the source functionality on your TV/Monitor/Projector.
Note: your Omnicast UHD is preset to turn on once you select the HDMI input on your TV/Monitor/Projector.
You can change this in the Preferences section on your device.

Network connections

1. Wired
1) Connect the network cable to the LAN port and
connect the other end of the network cable to
an available port on a LAN switch, router or
networked wall plate.
2) Go to Preferences → System Settings → More →
Ethernet to connect via Ethernet or adjust
wired settings.
3) Please turn o Wi-Fi before using Ethernet.
Firmware upgrade
1. Check and download new rmware from www.iconbit.com
(update.img) and place the new rmware onto the ROOT
of a USB drive.
2. Turn on the device and wait until home screen appears.
3. Plug the USB drive into USB port (3).
4. A rmware update con rmation dialog window will appear.
Select install, and wait for some time. The device will upgrade
and reboot.
5. Remove USB drive from USB port.
6. Go to Preferences → System Settings → Backup and reset menu and choose Factory data reset.
Note: all your data, les, apps and accounts information will be lost after rmware upgrade.
Applications
1. Please download apps from Google Play. If you can't access your Google account, please check your
network connection and system time/date.
2. Some apps require mouse functionality which can't be provided with an included remote control.
English 1/2
1 2 3
8
4 5 6
• USB: 2 x USB 2.0
• Power: DC 5V/2A
• Size / weight: 160 x 93 x 25 mm / 194 g
• Features: Octa-core Android box / Universal Remote
control / Digital signage (Autoplay mode)
HDMI
2. Wireless
1) Go to Preferences → System Settings → Wi-Fi
to connect to your Home Wi-Fi or adjust
wireless settings.
2) Please turn o Ethernet before using Wi-Fi.
1. CVBS out
2. USB 2.0
3. USB 2.0
4. LAN (RJ-45)
5. HDMI
6. DC in
7. Wi-Fi
7
8. Reset
TV
