FRONT AND REAR PANELS

Transmitter – clips into Techconnect faceplate
Receiver – positioned at display device
EQ Button
HDMI Output
(directly into display device)
HDMI Output (via RJ45)
HDMI Input (via RJ45)
5V 2A DC
Power Input
HDMI Input
Link LED
Shows that Tx is
connected to Rx
5V 0.8A DC Power Input
Via Micro USB
Backup; not usually required.
TC3_HDMITP2_manual_en.doc
EDID Reset
Button
4
