Configuration - level one WAB-6120 Handbuch

Configuration
Check Your Network Settings to login web UI
Please make sure your PC can get IP address automatically, so the router can communicate with
your PC during configuration.
Select "Control Panel" > "Network Connections".
Right click the "Local Area Connection" and choose "Properties".
Select the TCP/IP protocol for your network card.
Click on the Properties button. You should then see the following screen and make sure you
have selected "Obtain IP address automatically"
Open your WEB browser (Internet Explorer is recommended).
Then enter: http://192.168.1.1
User name: admin
Password: admin
- 5 -
