Install the hardware

!
IMPORTANT! - The casing of the main unit is not approved for outdoor use - the
product may only be installed in indoor environments.
Make a note of the serial number (S/N) located on the product label. This number may be required
during installation.
The main unit for the AXIS P1204/P1214/P1214-E/P1224-E can be mounted on a DIN rail or using
the supplied mounting rail.
1. If using the mounting rail, fasten it with screws to the wall or ceiling, using screws and plugs
appropriate for the wall/ceiling material. Note the direction of the two tabs on the rail, the tabs
align with the upper side of the main unit.
2. Attach the upper end of the main unit to the DIN rail or the mounting rail and snap the lower
end into place.
3. Proceed with the instructions for the appropriate camera model below.
