care and maintenance
Adjusting the headrest tension
Tools needed: flat-head screwdriver, long-handled 7/32-inch Allen key
1. Using a flat-head screwdriver, pop out the button on one side of the headrest.
2. Insert a long-handled 7/32-inch Allen key into the hole, then turn the bolt clockwise to increase the tension or
counter-clockwise to decrease the tension.
3. Using your fingers, insert the button back into the hole.
4. Repeat this procedure on the other side of the headrest, making the same adjustment as you did to the first side.
Allen key
Button
To replace a fuse:
1. Turn the Power switch to OFF and unplug the chair from the wall outlet.
2. Using your fingers, open the fuse compartment on the power panel, then turn the fuse holder
knob approximately 1/8 turn counter-clockwise. The fuse holder pops out.
3. Replace the fuse with a new fuse of the same value, then reinsert the fuse holder into the power panel.
4. Turn the fuse holder 1/8 turn clockwise to secure it.
5. Close the fuse compartment lid.
6. Plug the chair back into the wall outlet and turn it on.
24
humantouch.com
Specifications*
Operating voltage: 220-240V~ 50/60Hz
Power consumption: 150 Watts
Chair size (reclined): 172cm H x 70cm W x 74cm H
(67.5"L x 27.5"W x 29"H)
Product weight: 90.72kg
Maximum load weight: 130kg (285 Lbs.)
Rear clearance required: 55cm (21.5")
*Specifications are subject to change without prior notice.
Warranty
For warranty information, please contact your distributor.
