1. Description

The EX-1182VIS is a plug & play high-speed USB 3.1 (Gen1) hub for 4 devices with
15KV ESD Surge Protection and 3KV Optical Isolation. The EX-1182VIS provides four
USB 3.1 (Gen1) A-Ports for USB devices and one Upstream USB 3.1 (Gen1) B-Port to
the PC. It uses data transfer rates up to 5Gbit per second. The EX-1182VIS design fully
utilize the Genesys chipset, which represents the latest in high speed USB interface
technology. It provides a secure and very high data transfer on each single port. Via a
external power supply it is possible to provide a maximum of 1,5A on each USB port. It
provide self powered mode. Thus, it is imperative to connect the supplied power supply
to the EX-1182VIS. The EX-1182VIS is additionally equipped with a USB peak power
surge protection and optical isolation. The EX-1182VIS can installed to a wall with the
Wall Mounting Kit. Furthermore the EX-1182VIS support screw able USB 3.1 (Gen1)
ports.
Features:
•
Compatible for USB 1.1, 2.0, 3.0 & 3.1
•
Up to 480Mbit/s
•
All Operating Systems are supported
•
All ports are Screw Lock
•
15KV ESD Surge Protection
•
3KV Optical Isolation
•
Certificate for

2. Extent of Delivery

Before you connect the EX-1182VIS to your PC, you should first check the contents of
the delivery:
•
EX-1182VIS
•
Power Supply (5V/4A)
•
USB 3.1 (Gen1) Cable (screw lock)
•
Wall Mounting Kit
•
Manual
