PORT
Line (RJ11)
PS2
LAN( RJ-45)
Reset
POWER (jack)
POWER(switch)

1.4 Cabling

First you must connect the product to the ADSL line through
the RJ11 cable you have in equipment (in the port ADSL),
then connect to the RJ45 ports the PCs of your Lan or
others Switch. In the end. Once you've checked all the
connections, connect the AC Adapter to the WebShare
MEANING
Connect the supplied RJ-11 cable to
this port when connecting to the
ADSL/telephone network.
Connect a PS2/RS232(DB9) cable to
this port when connecting to a PC's
RS-232 port.
Connect an UTP Ethernet cable to
one of the four LAN ports when
connecting to a PC or an office/home
network of 10Mbps or 100Mbps.
After the device has turned on, press
it to reset the device or restore to
factory default settings. Hold the
button in until all lights on the modem
flash and it reboots with factory
default settings. Please Switch off
device and after Switch on again.
Connect the supplied power adapter
to this jack.
Power ON/OFF Switch.
