Checking control panels
To see if a control panel is a main control panel or an extra control panel:
OK
• Press on the control panel for 3 seconds to enter the user menu
• If the control panel is the main control panel, the display shows
right corner, see illustration →
• If the control panel is an extra control panel, the display shows
right corner, see illustration →

5.4 User and service menu

Menu functions on an extra control panel
Menu
0
USER MENU
1 CHIMNEY FAN
2 SYSTEM
21
22
23
24
3 LOG
31
32
33
EXIT
4 SERVICE
41 NETWORK
411
412
413
414
415
42 SETTINGS
421
422
423
424
425
426
427
43 TEST
431
EXIT
Text
USER MENUS
(Only accessible on the main control panel)
User configuration
LANGUAGE Operating interface language: English, German, French, Danish,
Norwegian, Swedish, Dutch, Finnish, Polish
CONTRAST Light intensity for text: 20 to 40
BACKLIGHT Light intensity for background lighting: 5 % to 100 %
BUZZER Beeps to indicate alarm 03 or 04, or that fuel should be added.
The sound can be stopped by pressing any key.
The setting for adding fuel may be either on or off
EXIT Return to user menu
Display history data
POWER Shows power consumption in kWh: Reset Yes / No
CONSUMPTION
ERROR LOG Shown only on the main control panel.
VERSION Displays software version
EXIT Return to user menu
Return to operation
SERVICE MENUS
Configuring the network
ADD DEVICE (Only accessible on the main control panel)
REMOVE DEVICE (Only accessible on the main control panel)
OPTIONS Add an option/device to the network
4131 ADD EXTRA PANEL Add an extra control panel to the master control panel
4132 REMOVE EXTRA PANEL Remove an extra control panel from the master control panel
EXIT Return to network menu
SIGNAL TEST Displays signal status
RESET Deletes all included devices: Yes / No.
EXIT Return to service menu
SERVICE LANGUAGE Language shown in user and service menu: English, French,
German
FACTORY SETTINGS Restore factory settings.
MINIMUM SPEED (Only accessible on the main control panel)
BOOST SPEED (Only accessible on the main control panel)
TEMPERATURE SENSOR (Only accessible on the main control panel)
CONTROL (Only accessible on the main control panel)
ALARM SETPOINT (Only accessible on the main control panel)
EXIT Return to service menu
FAN TEST Test chimney fan (Display of power consumption, speed, etc.)
EXIT Return to service menu
Return to user menu
USER MENU
1 CHIMNEY FAN
2 SYSTEM
[1]
in the top
3 LOG
4 SERVICE
EXIT
USER MENU
[2]
in the top
1 CHIMNEY FAN
2 SYSTEM
3 LOG
4 SERVICE
EXIT
Selection
3110061-ALL
[1]
[2]
Factory
setting
English
27
50 %
On
No
No
English
No
100 V
100 %
On
(Locked)
330 °C
