6. Functional components

34
9
13
10
11
No. Description
5 Heating handle
6 Nub plate and insert bowl
7 Drawer for granules
9 Compressed air supply
10 Handle plate reception
11 Plate reception
12 Ventilation valve
13 Tension ring
20 Heating
27 Display
33 Mains supply/fuse carrier
34 Activation lever
43 Main switch
44 Turnable pressure controller
