6. Functional components

34
9
4
13
10
11
No. Description
1 Scanner
2 Display
3 Key pad
4 Heating element
5 Heating handle
6 Nub plate and insert bowl
7 Drawer for granules
9 Compressed air supply
10 Handle plate reception
11 Plate reception
12 Ventilation valve
13 Tension ring
33 Mains supply/fuse carrier
34 Activation lever
43 Main switch
